Tripp Lite N39003M4SAP 40/100/400G Singlemode 9/125 OS2 Breakout Fiber Optic Cable (12F MTP/MPO-APC to 4x Duplex SN-UPC F/M), LSZH, Yellow, 3 m (9.8 ft.)
- MPN: N39003M4SAP
- UPC: 037332274519
- PPN: TRP-N390-03M-4S-AP
CAD
$434.41
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
40/100/400G Singlemode 9/125 OS2 Breakout Fiber Optic Cable (12F MTP/MPO-APC to 4x Duplex SN-UPC F/M), LSZH, Yellow, 3 m (9.8 ft.)
Documentation & Downloads
Specifications
Performance
| Network Compatibility | 40 Gbps; 100 Gbps; 400 Gbps |
|---|---|
| Attenuation @ 1310NM | 0.40 dB/km |
| Operating Temperature Range | 14° to 140°F (-10° to 60°C) |
| Operating Humidity Range | 5% to 85% RH, Non-Condensing |
| Wavelength | 1310nm; 1550nm |
|---|---|
| Attenuation @ 1550NM | 0.30 dB/km |
| Storage Temperature Range | 14° to 140°F (-10° to 60°C) |
| Storage Humidity Range | 5% to 85% RH, Non-Condensing |
Reference
| Product Warranty Period | Lifetime limited warranty |
|---|
Dimensions
| Cable Length | 3 m (9.8 ft) |
|---|---|
| Cable Outer Diameter | 3.0 mm |
| Core Diameter | 9.0 |
| Number of Fibers | 12 |
| Side B - Connector 1 | (4) SN DUPLEX (MALE) |
| Breakout | Yes |
| Minimum Bend Radius | 20 mm (Dynamic); 10 mm (Static) |
|---|---|
| Clad Diameter | 125.0 |
| Primary Coating Diameter | 245.0 |
| Side A - Connector 1 | 12F MPO (FEMALE) |
| Optical Port | MPO/MTP; SN |
Material
| Technology | Singlemode |
|---|---|
| Cable Jacket Color | Yellow |
| Cable Jacket Material | LSZH |
| Endface Polish | APC; UPC |
|---|---|
| Connector Color | Black, Blue, Green, White |
| Cable Jacket Rating | OFNR |
