ABB M125310000 41Z28 Terminal Bar, 5 Holes, Rated Current 63 A, Screw Terminals
- MPN: M125310000
- UPC: 888614116870
- PPN: ABB-M125310000
CAD
$8.98
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Terminals for consumer units - Terminal bars - 5 holes diam. 4,5 mm
Specifications
Additional
| Rated Current | 63 A |
|---|---|
| Number of Line Terminals | 7 |
| Hole Diameter | 4.5 mm |
| Product Net Weight | 0.028 kg |
| Terminal Type | Screw Terminals |
| Mounting Type | Other |
| Suitable For | IP65 junction boxes in polycarbonate |
| Accessory Type | Terminal bars |
| eClass | V11.0 : 27141106 |
| WEEE Category | Product Not in WEEE Scope |
| Rated Voltage | 400 V |
|---|---|
| Number of Holes | 5 |
| Product Net Depth / Length | 5 mm |
| Rated Cross-Section | 1 - Solid-Core 16 25 mm2, 2 - Fine-Strand with Cable End Sleeve 16 25 mm2, 3 - Fine-Strand without Cable End Sleeve 16 25 mm2, 4 - Multi-Wired 16 25 mm2 |
| Terminal Connection Type | Top |
| Insulation Material | Other |
| Color | Other |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| ETIM 9 | EC001284 - Single- and multi-pole terminal strip |
