Square D S33930 PowerPacT P I-Line Sub-Feed Lug Kit, 1200A, 3/0 to 600 kcmil
- MPN: S33930
- UPC: 785901231967
- PPN: SCH-S33930
CAD
$2115.78
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Square D sub-feed lug kits are UL Listed for use on Listed equipment. They have plug-on jaw construction and plug on to the I-Line bus stack in the same manner as branch circuit breakers. Lugs on these devices accommodate the same wire sizes as the equivalent ampere rated circuit breakers. This I-line sub-feed lug kit is 3 pole with 1200A current rating and is used for I-line, HCR-U panels with I-line circuit breakers. Mounting height is 15 inches and terminal data is 4 wires of AWG 3/0 - 600 kcmil. There are 4 conducters per lug.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
Physical Attributes
- Bar Length
- 381 mm
Complementary Attributes
- Line Rated Current
- 1200-1200 A
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Product Destination
- panelboard HCP 2184 mm 1067 mm, panelboard HCP-SU 2184 mm 660 mm
- Certificate Agency
- UL, CSA
- Local Publishable Date
- 2025-11-13
- Stocking Flag
- Y
- Serviceability
- No
- Field Service Division
- PPIBS
- Weee Product Category
- 4
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- China Rohs Label
- 7
- Without Single Use Plastic
- No
- Tier Id
- 2
- Function Option Id
- STANDARD
- Product Kit Identifier
- N
- Energy Efficiency Optimized
- False
- Product Or Component Type
- sub-feed lug
- Sustainable Packaging
- No
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market SegmentationCommercial, Industrial
Range Of ProductPowerPact P, I-Line
Local Data StatusPublishable
Return IndicatorY
Stock Policy1
TraceabilityNo
Weee ScopeIn
Scope PerimeterOutside of Europe
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date1909
China Rohs In ScopeYes
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
Tier2
Function OptionStandard
Awg GaugeAWG 3/0...600 kcmil
Product AvailabilityStock - Normally stocked in distribution facility
ReturnabilityYes
Halogen-free StatusHalogen free plastic parts product
Package Weight(Lbs)18.960 kg
Warranty (In Months)18
Environment Attributes Main
- Take Back
- No
- Recycled Metal Content At Cr Level
- 0 %
- Mercury Free
- Yes
- Halogen Content Performance
- Halogen free plastic parts product
- Packaging Without Single Use Plastic
- No
Halogene PerformanceHalogen free plastic parts product
China Rohs RegulationX
Eu Rohs DirectiveCompliant By Exemption
Packaging Made With Recycled CardboardYes
Reach RegulationReference contains Substances of Very High Concern above the threshold
General Attributes
- Range Of Product
- PowerPact P, I-Line
Product Or Component Typesub-feed lug
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
