Blackburn GLE 300-48 TN Tin Plated Aluminum Compression Lug 1 Hole for 300 kcmil Conductors
Blackburn GLE 300-48 TN Tin Plated Aluminum Compression Lug 1 Hole for 300 kcmil Conductors
- MPN: GLE 300-48 TN
- UPC: 783786729555
- PPN: T-B-GLE 300-48 TN
- UNSPSC: 39121409
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$72.73/ EA
Description
Tin Plated Aluminum One-Hole CSA Die Lug, Use with Aluminum and Copper Conductors, 300 Stranded-Compressed-Compact, Installing Die CSA26-12T. Length 3-3/4 inch. Pad 1-1/4 inch x 1-5/16 inch long x 23/64 inch thick. (1) 9/16 inch hole. Barrel 1-5/8 inch long. Oxide Inhibitor. Blue Cap.
Specifications
Additional Information
- Application
- Compression Connector
- Connection Type
- Compression
- Insulation Material
- None
- Product Type
- Compression Lug One Hole CSA Die
- Special Functions
- Use with Aluminum and Copper Conductors. Provide high strength and high conductivity. Prevents oxidation and keeps out moisture. Easy Identification.
- Surface Finishing
- Tin Plated
Brand / LabelHomac
Effective Date20080619
Product NameELECTRICAL TERMINAL<1000V
SizeLength 1.63 inches
StandardsANSI C119.4
Wire Size300 kcmil
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4543 >> Wire connectors
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
