APC BR1500GI Back-UPS Pro Tower UPS, 1500VA/865W, 10x IEC C13 Outlets, AVR, LCD
APC BR1500GI Back-UPS Pro Tower UPS, 1500VA/865W, 10x IEC C13 Outlets, AVR, LCD
- MPN: BR1500GI
- UPC: 731304268741
- PPN: APC-BR1500GI
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$1083.58/ EA
Description
Back-UPS Pro Tower UPS, 1500VA/865W, 10x IEC C13 Outlets, AVR, LCD
Features
- Adjustable voltage sensitivity — Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
- Adjustable voltage-transfer points — Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
- Audible alarms — Provides notification of changing utility power and UPS power conditions
- Automatic self-test — Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Battery failure notification — Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- Battery replacement without tools — Enables fast battery replacement, lowering Mean Time to Repair (MTTR).
- Battery-protected and surge-only outlets — Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment
- Boost and Trim Automatic Voltage Regulation (AVR) — Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Building Wiring Fault Indicator — This LED informs users of potentially dangerous wiring problems in the wall circuit.
- Cold-start capable — Provides temporary battery power when the utility power is out.
- Dataline surge protection — Provides protection of connected equipment from power surges on the data lines.
- Disconnected battery notification — Warns when a battery is not available to provide backup power.
- Extendable Run Time — Meet long run-time needs.
- Green mode — Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- Hot-swappable batteries — Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Intelligent battery management — Maximizes battery performance, life, and reliability through intelligent, precision charging.
- LCD graphics display — Text and mimic diagrams that display modes of operation, system parameters and alarms.
- Power-saving outlets — Automatically cuts power to idle equipment to conserve electricity.
- Resettable circuit breaker — Easy recovery from overloads; no need to replace a fuse. (Not available on Wall Tap SKUs)
- Safety-agency approved — The UPS is UL1778 Listed
- Serial connectivity — Provides management of the UPS via a serial port.
- Telephone dataline surge protection — Provides protection of connected equipment from power surges traveling on telephone lines.
- Transformer-block spaced outlets — Protect equipment with input transformer blocks without blocking access to other receptacles.
- USB connectivity — Provides management of the UPS via a USB port (not available on all models).
- User-replaceable batteries — Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Specifications
- Output Power Capacity, VA
- 1500 VA / 865 Watts
- Output Voltage, Frequency (on battery)
- 230V +/-8%, 50 or 60 Hz +/-1 Hz
- Waveform Type
- Stepped approximation to a sinewave
- Surge Protection
- AC power and data line surge protection on all outlets and data lines
- Interface Port(s)
- Optional Simple Signalling RS232 cable, USB
- Weight
- 13.4 kg
- Battery Type
- Sealed, lead-acid, maintenance-free
- Color
- Black
- Typical Recharge Time
- 8 hours
- RoHS
- Compliant
Input Voltage, Frequency230V, 50 or 60 Hz, +/- 3Hz
Output Connections12 outlets (10 IEC C13, 5 battery & surge, 5 surge only)
Surge Energy Rating441 J
TopologyLine interactive
Dimensions (H x W x D)30.1 x 11.2 x 38.0 cm (11.85 x 4.41 x 14.96 in)
Product OrientationTower
External Battery Pack CompatibilityYes (p/n: BR24BPG)
AlarmsVisual (LCD) and audible alarms
ApprovalsA-Tick, C-Tick, CE, GOST, GS Mark, Telepermit, TÜV, UL1778 Listed, NEMKO-GS
Warranty2 years repair or replace (3 years EU)
