Telemecanique Sensors XZCC12MDB50R Male, M12, 5 pin, shielded straight connector
- MPN: XZCC12MDB50R
- PPN: TES-XZCC12MDB50R
- UNSPSC: 39122230
CAD
$70.43
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Male, M12, 5 pin, shielded straight connector
Documentation & Downloads
Specifications
Key Specifications
| Collar Material | metal |
|---|---|
| Range Of Product | Telemecanique Cabling components |
| Status Led | without |
| Cable Connection | spring 0.5 mm² 4-8 mm |
| Electrical Connection | straight male connector M12, 5 pins |
|---|---|
| Accessory / Separate Part Category | cabling accessories |
| Accessory / Separate Part Type | connector |
Complementary
| Minimum Insulating Resistance | 1000 GΩ |
|---|---|
| Cable Connector Fixing | screw-on |
| Enclosure Material | metal |
| Contact Resistance | 8000 µOhm |
| [Ue] Rated Operational Voltage | 30 V AC || 36 V DC |
|---|---|
| Line Rated Current | 4 A |
| Net Weight | 0.02 kg |
Environment
| Ambient Air Temperature For Operation | -40-85 °C |
|---|
| Ip Degree Of Protection | IP67 |
|---|
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| Rohs Exemption Information | Yes |
|---|---|
| Toxic Heavy Metal Free | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Reach Free Of Svhc | Yes |
| Mercury Free | Yes |
|---|---|
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
