Schneider Electric 9001KYK31 Harmony 9001K Control Station with NEMA 3/4/13 Protection, 2 Push-Buttons

MPN: 9001KYK31
UPC: 785901513414
PPN: SCH-9001KYK31
UNSPSC: 39121565

$529.82

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This control station from Schneider Electric is designed for demanding industrial environments, featuring a robust construction that meets NEMA 3, 4, and 13 standards for protection against water, dust, and harsh conditions. The Harmony 9001K model is equipped with two push-buttons, providing reliable operation and control for various automation and control applications. Ideal for use in pendant stations, this device ensures safe and efficient functionality in a wide range of settings, making it a dependable solution for operators and engineers alike.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Mexico

Complementary Attributes

Ie Rated Operational Current Ac	10 A

Important Information Attributes

Persona Type Ids	BM9, EU, LC, OM, OM8, PB, SC, SI, VR
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Provided Equipment	contact block, legend plate
Local Publishable Date	2026-08-06
Weee Scope	In
Scope Perimeter	Outside of Europe
End Of Life Doc Ref	ENVEOLI121027EN
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1930
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	2
Function Option	Standard
Contact Block Name	KA1
Dc Control Voltage	125-600 V
Enclosure Material	die cast zinc alloy Gray
Product Availability	Non-Stock - Not normally stocked in distribution facility
Range Of Product	Harmony 9001K
Sustainable Packaging	Yes
Ac Control Voltage 60 Hz	125-600 V
Number Of Contacts As Normally Closed Contact	3
Number Of Push Buttons	2
Housing Color	grey
Enclosure/Cubicle Description	surface mounting
Customs Code	8537109170
Warranty In Months	18

Persona Type Names	Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market Segmentation	Commercial, Industrial
Local Data Status	Publishable
Return Indicator	N
Weee Product Category	5
Eoli Availability Display	Yes
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	2
Function Option Id	STANDARD
Product Kit Identifier	N
Control Station Composition	2 push-buttons 3 NO + 3 NC FORWARD-REVERSE-STOP
Device Short Name	KY
Housing Material	metal
Product Or Component Type	complete control station
Returnability	No
Ac Control Voltage 50 Hz	125-600 V
Number Of Command Positions	2
Number Of Contacts As Normally Open Contact	3
Color Of Cover	grey
Connections Terminals	screw-clamp terminals
Nbr. Of Units In Pkg.	1
Emergency Power Off Epo	no

Environment Attributes Main

Take Back	No
Recycled Metal Content At Cr Level	0 %
Toxic Heavy Metal Free	Yes
Circularity Profile	ENVEOLI121027EN
Eu Rohs Directive	Compliant
Nema Degree Of Protection	NEMA 4/13
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold

Reach Free Shvc	Yes
China Rohs Regulation	X
Mercury Free	Yes
Environmental Disclosure	ENVPEP1210027EN
Ip Degree Of Protection	IP66
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP1210027EN
