Burndy YA38L2NNTFX Copper Flex Conductor Terminal, 500 kcmil, 5.35 Inch Length

MPN: YA38L2NNTFX
UPC: 781810034743
PPN: BUR-510574

$165.29

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Flex Conductor Standard Barrel Narrow, 535.3 kcmil 1325/24 500 Flex, 1/2 in, 5.35 in L.

Documentation & Downloads

Specifications

Dimensions

Dimension - B Length fraction	1-7/16 in
Dimension - Bolt Hole Size inch	0.52 in
Dimension - D inch	3.03 in
Dimension - Length Overall inch	5.35 in
Dimension - Outside Diameter inch	1.25 in
Dimension - Strip Length inch	1-7/16
Dimension - Z inch	0.65 in

Dimension - B Length inch	1.45 in
Dimension - Bolt Size fraction	1/2
Dimension - L Length Overall mm	136 mm
Dimension - N inch	0.63 in
Dimension - Pad Width inch	1.63 in
Dimension - Stud Size inch	1/2
Physical Attribute - Tongue Angle	Straight

Certifications and Compliance

Certification - CSA Approved	Yes
Certification - UL Recognized	No
Standards - RoHS Compliance Status	CM

Certification - ETL	No
Certification - cULus	No
UL Listed	Yes

Conductor Related

Conductor - Copper DLO Size	535.3 (1325/#24) DLO
Conductor - Copper Flex G Size	500 kcmil
Conductor - Copper Flex H Size	500 kcmil
Conductor - Copper Flex I Size	500 kcmil
Conductor - Copper Flex K Size	500 kcmil
Conductor - Copper Flex M Size	500 kcmil

Conductor - Copper DLO Size Range	535.3 (1325/#24) DLO
Conductor - Copper Flex G Size Range	500 kcmil
Conductor - Copper Flex H Size Range	500 kcmil
Conductor - Copper Flex I Size Range	500 kcmil
Conductor - Copper Flex K Size Range	500 kcmil
Conductor - Copper Flex M Size Range	500 kcmil

General

Application	For Flex Conductor
Connector Type	Terminal
Feature - Barrel Type	Standard
Physical Attribute - Number of Holes	2
Plating Type	Tin - Electro Plated
Trade Name	HYLUG™
UPC	781810034743
