Square D TVS6DSPHC Diagnostic Display Kit 3 Phases 320 kA Surge Current 4-Wire
- MPN: TVS6DSPHC
- UPC: 785901253754
- PPN: SCH-TVS6DSPHC
- UNSPSC: 39121112
CAD
$4716.34
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The TVS6DSPHC Diagnostic Display Kit by Schneider Electric is designed to provide robust protection against surge currents, capable of handling up to 320 kA across three phases. This advanced surge protection solution integrates a diagnostic display feature that allows users to easily monitor the status of their surge protection, ensuring optimal performance and reliability. Ideal for critical industrial applications, this four-wire system is an essential asset for safeguarding sensitive equipment from voltage spikes, thereby extending the lifespan of your electrical systems.
Features
- Comes in a space-saving design and DOE 2016 fully compliant
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Mexico, United States |
|---|
| Weight | 344.73 g |
|---|
Complementary Attributes
| Ue Rated Operational Voltage | 208Y/120 V AC, 240/120 V HLD AC, 480Y/277 V AC, 600Y/347 V AC |
|---|
Important Information Attributes
| Persona Type Ids | EU, LC, OM |
|---|---|
| Provided Equipment | dry contactsalarm enable/disable switch, surge counterpush buttons diagnostic button |
| Carbon Footprint Of The End Of Life Phase C1 To C4 | 0.6 kg CO2 eq., 0.6204370531969918 |
| Carbon Footprint Of The Manufacturing Phase A1 To A3 | 4 kg CO2 eq., 3.8462117921035484 |
| Local Data Status | Publishable |
| Return Indicator | Y |
| Weee Product Category | 5 |
| Eoli Availability Display | Yes |
| Reach Full Compliance Status | Reference contains Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Reference contains Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant By Exemption |
| Rohs Eur Full Compliance Status | Compliant By Exemption |
| With Recycled Cardboard | No |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier Id | 2 |
| Function Option Id | STANDARD |
| Market Segmentation Id | COMMERCIAL |
| Product Kit Identifier | N |
| Local Signalling | status LED |
| Product Availability | Stock - Normally stocked in distribution facility |
| Range Of Product | Surgelogic |
| Software Version | v6.2.5-6 |
| Total Lifecycle Carbon Footprint | 89 kg CO2 eq. |
| Database Version | 2024-01 |
| Accessory / Separate Part Category | diagnostic accessory |
| Customs Code | 8536308000 |
| Functional Unit Description | Protect, against direct and indirect effects of lightning or against transient overvoltages, electronic equipment connected to networks with a rated operational voltage of up to 1000 V AC or 1500 V DC, via a surge arrester of type T, with Np poles, according to the appropriate use scenario, and for the reference service life of the product of 20 years. |
| Functional Unit Unit | unit |
| Energy Consumption On Product Lifetime In Kwh | 175.2 |
| Persona Type Names | End User, Contractor, Original Equipment Manufacturer |
|---|---|
| Carbon Footprint Of The Distribution Phase A4 | 0.04416808329692063, 0 kg CO2 eq. |
| Carbon Footprint Of The Installation Phase A5 | 0.0004180325804675474, 0 kg CO2 eq. |
| Carbon Footprint Of The Use Phase B2 B3 B4 B6 | 85 kg CO2 eq., 84.52448120922853 |
| Local Publishable Date | 2026-09-05 |
| Weee Scope | In |
| Scope Perimeter | Outside of Europe |
| End Of Life Doc Ref | ENVEOLI2508025EN |
| Reach Full Compliance Status Id | CONTAINS_SVHC |
| Rohs Eur In Scope | Yes |
| Rohs Eur Conformity Date | 2531 |
| China Rohs In Scope | No |
| Without Single Use Plastic | Yes |
| Dangerous Goods Code | LITHIUM METAL BATTERIES IN EQUIP. CELL : ≤ 1g AND > 4 Cells in Package |
| Tier | 2 |
| Function Option | Standard |
| Market Segmentation | Commercial |
| Energy Efficiency Optimized | False |
| Phase | 3 phase |
| Product Or Component Type | display unit |
| Returnability | Yes |
| Sustainable Packaging | No |
| Wiring Configuration | 4-wire |
| Data Source | extrapolated product |
| Nbr. Of Units In Pkg. | 1 |
| Warranty In Months | 18 |
| Functional Unit Quantity | 1 |
| Reference Lifetime In Y | 20 |
| Recyclability Potential In % | 69 |
Environment Attributes Main
| China Rohs Regulation | Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information. |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Carbon Footprint | 89.03571617040645 |
| Environmental Disclosure | ENVPEP2508025EN |
| Packaging Made With Recycled Cardboard | No |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Pep Verification Date | 2025-08-01 |
| Psr Version | PSR-0005-ed3.1-EN-2023 12 08 |
| Take Back | No |
|---|---|
| Mercury Free | Yes |
| Circularity Profile | ENVEOLI2508025EN |
| Eu Rohs Directive | Compliant By Exemption |
| Packaging Without Single Use Plastic | Yes |
| Pep Code | ENVPEP2508025EN |
| Pcr Version | PEP-PCR-ed4-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
General Attributes
| Provided Equipment | dry contactsalarm enable/disable switch, surge counterpush buttons diagnostic button |
|---|---|
| Product Or Component Type | display unit |
| Phase | 3 phase |
|---|---|
| Range Of Product | Surgelogic |
Surge Protection And Filtering Attributes
| Surge Current | 320 kA per phase, 480 kA per phase |
|---|
Contractual Warranty Attributes
| Warranty | 18 months |
|---|
