Schneider Electric REL52813 Easergy P3 Analog Temperature Module with 12 RTD Inputs, 24V DC, IP20
- MPN: REL52813
- PPN: SCH-REL52813
- UNSPSC: 39121552
CAD
$1218.71
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
This analog temperature module for easergy P3 is used to connect temperature sensors from the field to the Easergy P3 devices using a communication port RS485 by twist-pair or fiber optic. The modules have 4 analog input and 4 output to use in the special controls functions. The module accepts supply voltage 24 VDC. The degree of protection is IP20. The module can be mounted using DIN-rail.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Brazil, Finland, Mexico, Sweden, United States |
|---|
Communications & Management Attributes
| Communication Port Support | serial link, fiber optic |
|---|
Complementary Attributes
| Us Rated Supply Voltage | 24 V DC |
|---|
Important Information Attributes
| Mounting Support | 35 mm symmetrical DIN rail, wall mounted |
|---|---|
| Local Publishable Date | 2025-12-12 |
| Device Type | Relay, Control & Measurement - Protection relay |
| Traceability | No |
| Average Life Duration | 15 year(s) |
| Scope Perimeter | At least in Europe |
| End Of Life Doc Ref | ENVEOLI1411007_V1 |
| Rohs Eur Status | Compliant By Exemption |
| Rohs Eur Full Compliance Status | Compliant By Exemption |
| China Rohs Label | 7 |
| Without Single Use Plastic | No |
| Product Kit Identifier | N |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Range Of Product | Easergy P3 |
| Sustainable Packaging | No |
| Nbr. Of Units In Pkg. | 1 |
| Warranty In Months | 18 |
| Local Data Status | Publishable |
|---|---|
| Return Indicator | N |
| Serviceability | No |
| Field Service Division | DPIBS |
| Weee Scope | Out |
| Eoli Availability Display | Yes |
| Rohs Eur In Scope | No |
| Rohs Eur Conformity Date | 2012 |
| China Rohs In Scope | Yes |
| With Recycled Cardboard | No |
| Product Contributes To Saved And Avoided Emissions | No |
| Energy Efficiency Optimized | False |
| Product Or Component Type | analog temperature module |
| Returnability | No |
| Temperature Probe Type | Pt 100, Ni 100, Ni 120, Cu 10 |
| Customs Code | 8517620090 |
Environment Attributes Main
| Take Back | No |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Mercury Free | Yes |
| Circularity Profile | ENVEOLI1411007_V1 |
| Eu Rohs Directive | Compliant By Exemption |
| Packaging Without Single Use Plastic | No |
| Pep Code | ENVPEP1411007_V1 |
| Reach Free Shvc | Yes |
|---|---|
| China Rohs Regulation | X |
| Ambient Air Temperature For Operation | 0-55 °C |
| Environmental Disclosure | ENVPEP1411007_V1 |
| Packaging Made With Recycled Cardboard | No |
| Reach Free Of Svhc | Yes |
General Attributes
| Product Or Component Type | analog temperature module |
|---|
| Range Of Product | Easergy P3 |
|---|
Output Attributes
| Analogue Output Number | 4 |
|---|
Input Attributes
| Analogue Input Number | 4 |
|---|
| Number Of Inputs | 12 RTD temperature sensor)1 PTC temperature sensor) |
|---|
