Schneider Electric REL52814 Easergy P3 Analog Temperature Module 12 RTD Inputs 48-230V
- MPN: REL52814
- PPN: SCH-REL52814
CAD
$1218.71
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This analog temperature module for easergy P3 is used to connect temperature sensors from the field to the Easergy P3 devices using a communication port RS485 by twist-pair or fiber optic. The modules have 4 analog input and 4 output to use in the special controls functions. The module accepts supply voltage ranging from 48 to 230VAC/VDC. The degree of protection is IP20. The module can be mounted using DIN-rail.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Brazil, Finland, France, Sweden, United States
Communications & Management Attributes
- Communication Port Support
- fiber optic, serial link
Important Information Attributes
- Mounting Support
- wall mounted, 35 mm symmetrical DIN rail
- Local Publishable Date
- 2025-07-09
- Stocking Flag
- Y
- Device Type
- Relay, Control & Measurement - Protection relay
- Traceability
- No
- Average Life Duration
- 15 year(s)
- Scope Perimeter
- At least in Europe
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- China Rohs Label
- 7
- Without Single Use Plastic
- No
- Product Kit Identifier
- N
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Range Of Product
- Easergy P3
- Sustainable Packaging
- No
- [Us] Rated Supply Voltage
- 48...230 V AC/DC
- Package Weight(Lbs)
- 1.240 kg
- Warranty (In Months)
- 18
Local Data StatusPublishable
Return IndicatorN
Stock Policy2
ServiceabilityNo
Field Service DivisionDPIBS
Weee ScopeOut
Rohs Eur In ScopeNo
Rohs Eur Conformity Date2012
China Rohs In ScopeYes
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
Energy Efficiency OptimizedFalse
Product Or Component Typeanalog temperature module
ReturnabilityNo
Temperature Probe TypePt 100, Ni 100, Ni 120, Cu 10
Nbr. Of Units In Pkg.1
Take-backNo
Customs Code8517620090
Environment Attributes Main
- Take Back
- No
- Recycled Metal Content At Cr Level
- 0 %
- Mercury Free
- Yes
- Eu Rohs Directive
- Compliant By Exemption
- Packaging Without Single Use Plastic
- No
Reach Free ShvcYes
China Rohs RegulationX
Ambient Air Temperature For Operation0-55 °C
Packaging Made With Recycled CardboardNo
Reach Free Of SvhcYes
General Attributes
- Product Or Component Type
- analog temperature module
Range Of ProductEasergy P3
Output Attributes
- Analogue Output Number
- 4
Input Attributes
- Analogue Input Number
- 4
Number Of Inputs12 RTD temperature sensor)1 PTC temperature sensor)
