Bussmann FWX-1500AH High Speed Fuse 1500A 250V with Cylindrical Shape and 66MM Length
- MPN: FWX-1500AH
- UPC: 051712795630
- PPN: BUS-FWX-1500AH
CAD
$1378.93
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
High Speed Fuse 1500A 250V with Cylindrical Shape and 66MM Length
Documentation & Downloads
Specifications
Key Specifications
| Height | 76.2 MM |
|---|---|
| Width | 76.2 MM |
| Type | Fuse |
| Voltage Rating Numeric | 250 V |
| Amperage Rating Numeric | 1500 A |
| Connection | Blade end X blade end |
| Mounting | Flush |
| Breaking Capacity | 200 A |
| Fuse Shape | cylindrical with flush end contacts |
| Insulated Metal Gripping Lugs (IMGL) | No |
| Utilization category | aR (accompanied semiconductor protection) |
| Watt Losses | 140W |
| Length | 66 MM |
|---|---|
| Weight | 19.5 G |
| Application | DC common bus, DC drives, power converters/rectifiers and reduced voltage starters |
| Amperage Rating | 1500A |
| Interrupt Rating | 200 kAIC Vac, 50 kAIC at 250 Vdc |
| Construction Size | Other |
| Packaging Type | Standard |
| Clearing (I2T) | Clearing at 250V: 880000 |
| Fuse Indicator | None |
| Pre Arc (I2T) | 120000 |
| Voltage Type | AC |
