Bussmann FWJ-150A Eaton Bussmann series high speed North American fuse

Eaton Bussmann series high speed North American fuse - https://media.province-electric.com/eaton/2019q2/8f815dce753377e78cef863536fe2853e6b95c38-medium.png

Eaton Bussmann series high speed North American fuse - https://media.province-electric.com/eaton/2019q2/feb3ab99bb6a434257f01d615da259725500f12e-medium.png

Eaton Bussmann series high speed North American fuse - https://media.province-electric.com/eaton/2019q2/eb5714f6860042857ff5ed231cc73e8605c0c164-medium.png

Eaton Bussmann series high speed North American fuse

MPN: FWJ-150A
UPC: 051712796323
PPN: BUS-FWJ-150A

Spec sheet

Compare

Loading compare button...

Available to Order

Company Stock:

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$298.97/ EA

Qty:

Loading add to cart quantity...

Description

Eaton Bussmann series high speed North American fuse

Specifications

Height: 25 MM

Width: 25 MM

Type: Fuse

Voltage Rating: 700 Vac/dc

Amperage Rating: 150A

Interrupt Rating: 25 kAIC (35-200A), 100 kAIC (250-2000A), 50 kAIC at 800 Vdc (35-200A, 450-600A)

Construction Size: Other

Packaging Type: Standard

Fuse Shape: centre-bolted tags

Insulated Metal Gripping Lugs (IMGL): No

Voltage Type: AC/DC

Rated switching capacity: 25 A

Length144 MM

Weight4.4 LB

Applicationprotection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters

Voltage Rating Numeric1000 V

Amperage Rating Numeric150 A

ConnectionBlade end X blade end

MountingStud

Clearing (I2T)Clearing at 1000V: 45000

Fuse IndicatorNone

Pre Arc (I2T)6300

Watt Losses25W

Downloads
