Bussmann

Bussmann FWA-800A Eaton Bussmann series high speed North American fuse

Eaton Bussmann series high speed North American fuse
Eaton Bussmann series high speed North American fuse
Eaton Bussmann series high speed North American fuse
  • MPN: FWA-800A
  • UPC: 051712795456
  • PPN: BUS-FWA-800A

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$195.42/ EA

Description

Eaton Bussmann series high speed North American fuse

Specifications

Specifications

Height
25.4 MM
Width
25.4 MM
Type
Fuse
Voltage Rating
500 Vac/dc (35-800A only)
Amperage Rating
800A
Interrupt Rating
200 kAIC Vac (70-1000A), 20 kAIC at 150 Vdc (70-800A), 100 kAIC at 80 Vdc (70-1000A)
Construction Size
Other
Packaging Type
Standard
Fuse Shape
cylindrical with centre-bolted tags
Insulated Metal Gripping Lugs (IMGL)
No
Voltage Type
AC/DC
Rated switching capacity
200 A
Length89 MM
Weight192 G
ApplicationDC common bus, DC drives, power converters/rectifiers and reduced voltage starters
Voltage Rating Numeric150 V
Amperage Rating Numeric800 A
ConnectionBlade end X blade end
MountingStud
Clearing (I2T)280000
Fuse IndicatorNone
Pre Arc (I2T)92000
Watt Losses58
