Tripp Lite ECO350UPS ECO Series 120V 350VA 180W Energy-Saving Standby UPS with USB and 6 Outlets
Tripp Lite ECO350UPS ECO Series 120V 350VA 180W Energy-Saving Standby UPS with USB and 6 Outlets
- MPN: ECO350UPS
- UPC: 037332143877
- PPN: TRP-ECO350UPS
Spec sheet
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$159.15/ EA
Description
ECO Series 120V 350VA 180W Energy-Saving Standby UPS with USB and 6 Outlets
Features
- 350VA ultra-compact 120V standby UPS, energy-saving ECO outlets
- Maintains AC output during power failures, 99% line mode efficiency
- ENERGY STAR Version 2.0 qualified
- ECO option turns off set of two ECO outlets when the computer is not in use
- USB, TEL/DSL protection, Wall mountable, Surge-only outlets
- NEMA 5-15P input plug and 6 NEMA 5-15R outlets
- 3-year limited warranty
- $100,000 Ultimate Lifetime Insurance
Specifications
Surge / Noise Suppression
- UPS AC Suppression Joule Rating
- 420
- UPS Dataline Suppression
- 1 line TEL/DSL (1 in / 1 out)
UPS AC Suppression Response TimeInstantaneous
EMI / RFI AC Noise SuppressionYes
Battery
- Half Load Runtime (min.)
- 11.3 min. (90w)
- Internal UPS Replacement Battery Cartridge
- IMPORTANT BATTERY REPLACEMENT INFORMATION > If your ECO350UPS has no battery access door, please contact a local electronics repair technician to source and install a matching replacement battery; If your ECO350UPS does have a battery replacement door and the original battery inside has a rating of 12V 2.8AH, please contact Tripp Lite for assistance
DC System Voltage (VDC)12
Expandable RuntimeNo
Certifications
- UPS Certifications
- ENERGY STAR Qualified; Meets FCC Part 15 Category B (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
Physical
- Installation Form Factors Supported with Included Accessories
- Tower; Ultra-compact desktop; Wallmount
- Primary UPS Depth (mm)
- 163
- Primary UPS Width (mm)
- 203
- Shipping Weight (lbs.)
- 5.98
- UPS Power Module Dimensions (hwd, in.)
- 3 x 8 x 6.4
- UPS Power Module Weight (lbs.)
- 5.2
Primary Form FactorDesktop
Primary UPS Height (mm)76
Shipping Dimensions (hwd / in.)4.00 x 7.70 x 11.30
UPS Housing MaterialABS
UPS Power Module Weight (kg)2.36
User Interface, Alerts & Controls
- Switches
- Combination switch controls on/off power status and self-test operation; second recessed push-button switch enables ECO outlet switching
- LED Indicators
- 3 LEDs indicate power status, overload/check battery and ECO-mode status
Audible AlarmAudible alarm indicates power-failure and overload status
Input
- Rated input current (Maximum Load)
- 10A
- UPS Input Connection Type
- 5-15P; Right-Angled
- Recommended Electrical Service
- 15A 120V
Nominal Input Voltage(s) Supported120V AC
UPS Input Cord Length (ft.)6
Input PhaseSingle-Phase
Output
- Output Volt Amp Capacity (VA)
- 350
- Nominal Voltage Details
- 115v nominal output in battery mode
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Output AC Waveform (AC Mode)
- Sine wave
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- Individually Controllable Load Banks
- No
Output Watt Capacity (Watts)180
Frequency Compatibility60 Hz
UPS Output Receptacles (Surge Suppression Only)3 UPS outlets, 3 surge-only outlets
Output AC Waveform (Battery Mode)PWM sine wave
Output Receptacles(6) 5-15R
Communications
- PowerAlert Software
- For local monitoring via the UPS’s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Communications Interface
- USB (HID enabled)
Communications CableRJ to USB interface cable included
Network UPS Tools CompatibilityNUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
Environmental
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Relative Humidity
- 0 to 95%, non-condensing
- AC Mode Efficiency Rating (100% Load)
- 99%
Storage Temperature Range+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
AC Mode BTU / Hr. (Full Load)6
Overview
- UPC Code
- 037332143877
UPS TypeStandby
Special Features
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
Green Energy-Saving FeaturesGreater than 95% efficiency - GREEN UPS; Power saving auto-shutoff ECO outlets
Warranty
- Product Warranty Period (U.S. & Canada)
- 3-year limited warranty
Connected Equipment Insurance (U.S., Canada & Puerto Rico)$100,000 Ultimate Lifetime Insurance
Line / Battery Transfer
- Transfer Time
- AC to battery mode: 4 milliseconds; Battery to AC mode: 3 milliseconds
- High Voltage Transfer to Battery Power (Setpoint)
- 139
Low Voltage Transfer to Battery Power (Setpoint)99
