Hubbell Premise Wiring

Hubbell Premise Wiring SFSCSGNW Fiber Optic Snap-Fit SC Simplex Connectors with Zircon Sleeves, 0.700 Inch Width, Green

Fiber Optic Snap-Fit SC Simplex Connectors with Zircon Sleeves, 0.700 Inch Width, Green
  • MPN: SFSCSGNW
  • UPC: 662620241777
  • PPN: HBL-SFSCSGNW
  • UNSPSC: 43223310

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$22.48/ EA

Description

Fiber Optic Connectors, Snap-Fit, SC, Simplex, Zircon Sleeves, Green, White Housing.

Features

  • Snap Fit
  • White Housing
  • Standard
  • SC Simplex
  • Green Adapter
  • Standard Product

Specifications

Specifications

Country of Origin
Taiwan
Width
0.700 in
Size
.58" X .76"
Color
Green
Insertion Loss
0.75 dB
Repeatability
0.1 dB
Service Life
500 matings
Standard
Telcordia GR-326-CORE;TIA-568-C.3;TIA-604 FOCIS-3
Temperature Rating
0C to 70C
Connectivity
Receptacle
Style
SC Simplex
Description - Invoice
FIBER, SNAP-FIT,SC SMPLX,ZIRC,GN,WH
Harmonization Code
8536700000
MSDS Flag
No
Sub Class Code
HPWALL2
Material
Ceramic
BOX SIZE
4.400x3.400x6.400 (in)
Carton - Number of Sub Packs
25
Carton - SCC-14 Next Lower Level Sub Pack
662620241777
Each - Pack Description
Each
Color - HousingWhite
Industry Standard(s)Telcordia GR-326-CORE;TIA-568-C.3;TIA-604 FOCIS-3
ApplicationData Outlet
Fiber Size125 Micron
MountingStandard
Return Loss55
Special FeaturesStandard Product
Sub BrandOptiChannel
General Literature Asset 1 Display TextIntegrating AV Systems
Mounting TypeStandard
Class CodeA68
Freight Class Code06168002
Image Actual Or RepresentativeA
Replaced Catalog NumberSFSCGNW;SFSCAW
Material - Mounting HardwareSnap-In, Keystone
Base Unit of MeasureEA
Carton - Gross Weight per Pack1.250 lb.
Carton - Pack DescriptionCarton
Carton - Total Units25 EA
Lowest Level UOMEach

Certifications

EU RoHS Indicator
Yes
