Mersen GGM1 Fast-Acting Glass Fuse 5x20mm 250V 1A
- MPN: GGM1
- UPC: 782001762117
- PPN: FER-GGM1
CAD
$1.42
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Up to 250V, Fast Acting, Glass, 5mm x 20mm
Features
- Engineered with a highly responsive fast-acting characteristic, the GGM1 is designed to interrupt the circuit almost instantaneously upon detecting an overcurrent. This rapid-clearance performance is critical for protecting delicate internal components, such as control boards and microprocessors, from the thermal damage that can occur during even brief electrical faults.
- Featuring the standard global 5mm x 20mm (3/16" x 3/4") footprint, this miniature glass fuse is the industry-standard replacement for most small appliances, consumer electronics, and industrial control circuits. The compact, standardized ferrule design ensures a perfect fit into PCB-mount clips or panel-mount fuse holders, restoring power without the need for hardware modifications.
- Precisely rated for 1 Amp at 250V AC, this fuse provides specialized low-amperage protection for circuits where high-current fuses would fail to trip safely. This specific rating is ideal for multi-meters, laboratory equipment, and small power supplies, ensuring that any surge beyond the 1A threshold is halted before it can compromise your expensive equipment.
- The high-clarity glass tube construction allows for immediate visual verification of the internal fuse element. By eliminating the need for diagnostic testing with a continuity meter, maintenance staff and DIYers can instantly identify a blown circuit, significantly reducing troubleshooting time and simplifying the repair process in complex electronic arrays.
Documentation & Downloads
Specifications
Additional
- Ampere Rating
- 1 A
- Speed/Characteristic
- Fast-Acting
- Fuse Size
- 5x20 mm (0.20 in x 0.79 in)
- Mounting
- Clip
- Weight
- 0.01 lb
Rated Voltage250 V AC
Fuse ClassSupplemental
Connection/Terminal TypeFerrule
Body/Insulating MaterialGlass
ROHS CompliantYes
