Mersen GGM10 Fast-Acting Fuse 250V 10A Glass 5mm x 20mm
- MPN: GGM10
- UPC: 782001762247
- PPN: FER-GGM10
CAD
$1.42
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Up to 250V, Fast Acting, Glass, 5mm x 20mm
Features
- Engineered with a highly responsive, fast-acting design, this supplemental fuse opens almost instantly when an overcurrent spike occurs. This rapid clear time limits thermal and electrical energy pass-through, successfully isolating downstream faults to safeguard delicate control circuits, power supplies, and printed circuit boards from permanent damage.
- Featuring a standard 5 times 20 mm (0.2 in times 0.79 in) miniature design, this cartridge fuse takes up minimal real estate inside dense electrical assemblies. It drops perfectly into standard 5x20mm PCB clips, panel-mount blocks, and inline holders, making it a drop-in replacement that eliminates the need for expensive circuit layout re-engineering.
- Constructed with a crystal-clear glass body, this fuse allows maintenance technicians and field engineers to complete an instant visual inspection of the internal element. By making a melted or broken filament immediately obvious, it shortens troubleshooting workflows during diagnostic inspections and reduces system downtime.
- Providing a robust 10-amp current capacity and a 250V AC operating threshold, this supplemental protection device is optimized for small-motor, appliance, and instrument networks. Its 100-amp interrupting rating ensures safe electrical containment during minor shorts, keeping your commercial facility compliant with UL 248-14 and CSA standards.
Documentation & Downloads
Specifications
Additional
- Voltage
- 250 V
- Fuse Type
- Fast-Acting
- AC or DC
- AC
- Length
- 0.79 in
- Material
- Glass
- Connection Type
- Ferrule
- RoHS Compliance
- Yes
Amperage10 A
Fuse ClassSupplemental
Size5 x 20 mm
Weight0.01 lb
MountingClip
Body TypeMidget
CertificationUL Listed, CSA Certified
