Mersen GGM15 Fast-Acting Fuse 5x20mm 15A 250V Glass Body
- MPN: GGM15
- UPC: 782001768201
- PPN: FER-GGM15
CAD
$1.42
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Up to 250V, Fast Acting, Glass, 5mm x 20mm
Features
- This miniature cartridge fuse features the industry-standard 5mm x 20mm (0.2" x 0.79") cylindrical body with ferrule terminal connections. It perfectly replaces blown fuses in any standard clip-mount or panel-mount holder without forcing you to modify your existing circuit boards or equipment layout.
- Engineered with a robust 15 Amp current rating and a maximum voltage rating of 250 VAC, this fuse provides heavy-duty supplemental protection. It handles steady operational currents right up to its threshold, preventing nuisance trips while remaining ready to isolate electrical faults instantly.
- As a dedicated fast-acting glass fuse, the GGM15 drops the circuit open almost instantly when an overcurrent event occurs. This rapid clear time limits the energy let-through, protecting sensitive downstream solid-state electronics, power supplies, and control circuits from catastrophic thermal damage.
- Constructed with a clear glass body and a non-indicating design, this fuse allows for immediate visual inspection of the internal element. You can easily spot a fractured or melted filament at a glance, minimizing troubleshooting downtime when diagnosing a dead circuit.
Documentation & Downloads
Specifications
Additional
- Ampere Rating
- 15 A
- Speed/Characteristic
- Fast-Acting
- Fuse Size
- 5 x 20 mm
- Connection/Terminal Type
- Ferrule
- Weight
- 0.01 lb
- ROHS Compliant
- Yes
Voltage250 V AC
Length0.79 in
MountingClip
Body/Insulating MaterialGlass
Fuse ClassSupplemental
AC or DCAC
