Schneider Electric XB5FG61 Key switch selector flush mounted, Harmony XB5, plastic, black, 30mm, key 455, 2 positions, spring return right to left, 1 NO

  • MPN: XB5FG61
  • PPN: SCH-XB5FG61
  • UNSPSC: 39122217

CAD

$140.29

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

Key switch selector flush mounted, Harmony XB5, plastic, black, 30mm, key 455, 2 positions, spring return right to left, 1 NO

Features

  • Quick and easy assembly and disassembly
  • Robustness to withstand harsh environments
  • With various types of connection: screw clamp, connector, Faston connector, spring terminal, or printed circuit board
  • A wide choice of contact blocks for general purposes or specific applications (low current, standard)
  • Excellent mechanical connection with operator head
  • A large set of accessories to customize your panels
  • Allows a clearer view of control features.
  • Provides better perceived quality of machines and panels
  • Innovative design without compromise on cost.
  • Delivers extremely robust performance even in severe environments

Documentation & Downloads

Specifications

Key Specifications

Country of OriginFrance
Depth98.5 mm
Weight90 g

Complementary Attributes

Ie Rated Operational Current3 A 240 V, AC-15, A600 IEC 60947-5-16 A 120 V, AC-15, A600 IEC 60947-5-10.1 A 600 V, DC-13, Q600 IEC 60947-5-10.27 A 250 V, DC-13, Q600 IEC 60947-5-10.55 A 125 V, DC-13, Q600 IEC 60947-5-1, 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
Uimp Rated Impulse Withstand Voltage6 kV IEC 60947-1
Ui Rated Insulation Voltage600 V 3)IEC 60947-1

Important Information Attributes

Persona Type IdsBM9, EU, LC, OM, OM8, PB, SC, SI, VR
Market Segmentation IdCOMMERCIAL, INDUSTRIAL
Bezel Materialdark grey plastic, dark grey plastic
Electrical Durability1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
Key Withdrawal Positionleft, left
Certificate AgencyUL Listed, CSA
Carbon Footprint Of The Distribution Phase A40.0117692308, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase A50.0138750778, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase B2 B3 B4 B60.1 kg CO2 eq., 0.07914
Local Publishable Date2026-08-10
Weee ScopeIn
Scope PerimeterAt least in Europe
End Of Life Doc RefENVEOLI2308009EN
Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
Rohs Eur StatusCompliant By Exemption
Rohs Eur Full Compliance StatusCompliant By Exemption
China Rohs Label5
Without Single Use PlasticYes
Tier Id2
Function Option IdSTANDARD
Product Kit IdentifierN
Contact Operationslow-break
Contacts Type And Composition1 NO
Device Short NameXB5F
Gcr BridgeXB5FGCUST02
Mechanical Durability1000000 cycles
Operator Position Information2 positions 90°
Positive Openingwithout
Product Or Component Typeselector switch
Protective TreatmentTH
Resistance To High Pressure Washer7000000 Pa 55 °C 0.1 m
Sale Per Indivisible Quantity1
Shock Resistance30 gn 18 ms) half sine wave acceleration IEC 60068-2-2750 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Sustainable PackagingYes
Total Lifecycle Carbon Footprint0.8 kg CO2 eq.
Type Of Operatorright to left spring return
Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Type Of Operator 3 Type Of Operatorspring return
Database Version2022-01
Height Nominal42 mm
Cap/Operator Or Lens Colourblack
Customs Code8536509020
Short Circuit Protection10 A cartridge fuse gG IEC 60947-5-1
Warranty In Months18
Functional Unit Quantity1
Reference Lifetime In Y10
Persona Type NamesCharge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market SegmentationCommercial, Industrial
Customizable1, no
Electrical Reliabilityλ < 10exp(-6) 5 V, 1 mA in clean environment IEC 60947-5-4, λ < 10exp(-8) 17 V, 5 mA in clean environment IEC 60947-5-4
Shape Of Screw Headcross Philips no 1, cross pozidriv No 1slotted flat Ø 4 mm, slotted flat Ø 5.5 mm
Terminals Description Iso N°1(13-14)NO, (13-14)NO
Carbon Footprint Of The End Of Life Phase C1 To C40.1 kg CO2 eq., 0.1221241966
Carbon Footprint Of The Manufacturing Phase A1 To A30.6 kg CO2 eq., 0.612384408
Local Data StatusPublishable
Return IndicatorY
Weee Product Category5
Eoli Availability DisplayYes
Product Repair Index Dam DocXB4BS8442-ENVREPAIR-A-EN
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeNo
Rohs Eur Conformity Date1930
China Rohs In ScopeYes
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
Tier2
Function OptionStandard
Compatibility CodeXB5
Contacts Materialsilver alloy (Ag/Ni)
Contacts Usagestandard contacts
Electrical Shock Protection Classclass II conforming to IEC 60536
Head Typebuilt-in-flush
Mounting Diameter30.5 mm
Operator Profileblack key switch, unmarked
Product AvailabilityStock - Normally stocked in distribution facility
Product Repair IndexA
Range Of ProductHarmony XB5
ReturnabilityYes
Shape Of Signaling Unit Headround
Software Versionv5.9.4
Tightening Torque0.8-1.2 N.m IEC 60947-1
Type Of Keylockkey 455
Vibration Resistance5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6
Connections Terminalsscrew clamp terminals, = 1 x 0.22 mm² without cable end IEC 60947-1
Type Of Operator 3 Returnright to left
Data Sourceextrapolated product
Width Nominal36.6 mm
Nbr. Of Units In Pkg.1
Ith Conventional Free Air Thermal Current10 A IEC 60947-5-1
Product Repair Index Dam Document IdXB4BS8442-ENVREPAIR-A-EN
Functional Unit DescriptionThis switch s primary function is to control devices as well as switch between a minimum of two electrical circuits with a power consumption of 0.004 W with use rate of 72% for a period of 10 years and product is adhering to standards EN/IEC 60947-5-1. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation.
Functional Unit UnitUnit

Environment Attributes Main

Ambient Air Temperature For Operation-40-70 °C, -40-70 °C
Ip Degree Of ProtectionIP66 IEC 60529, IP67, IP69, IP69K
Take BackNo
China Rohs RegulationX
Carbon Footprint0.8392929131
Environmental DisclosureENVPEP2308009EN
Packaging Made With Recycled CardboardYes
Reach RegulationReference contains Substances of Very High Concern above the threshold
Pep Verification Date2023-08-01
Psr VersionPSR-0005-ed2-2016 03 29
Ambient Air Temperature For Storage-40-70 °C, -40-70 °C
Nema Degree Of ProtectionUL type 4X/13, NEMA 13, NEMA 4X
Recycled Metal Content At Cr Level0 %
Mercury FreeYes
Circularity ProfileENVEOLI2308009EN
Eu Rohs DirectiveCompliant By Exemption
Packaging Without Single Use PlasticYes
Pep CodeENVPEP2308009EN
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent internal review

General Attributes

Product Or Component Typeselector switch
Range Of ProductHarmony XB5

ETIM

ETIM 8EC001029
ETIM 10EC001029
ETIM 9EC001029

Contractual Warranty Attributes

Warranty Period18 months
Warranty18 months

Overview Attributes

Device Presentationcomplete product
