Hubbell Wiring Device-Kellems L430P12 IEC Pin and Sleeve Male Plug 30A 125/250V 3-Pole 4-Wire Orange
- MPN: L430P12
- UPC: 783585888002
- PPN: HBL-L430P12
- UNSPSC: 39121402
CAD
$437.77
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Heavy Duty Products, IEC Pin and Sleeve Devices, Industrial Grade, Male, Plug, 30A 125/250V, 3-Pole 4-Wire Grounding, Terminal Screws, Orange
Features
- Solid one-piece pins for reliable electrical contact
- Recessed pins are protected from impact and abuse
- Integrated Cord Grip limits strain on terminals
- Watertight
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
- Width
- 4.370 in
- Amperage Rating
- 30 A
- Color
- Orange
- Environmental Conditions
- Indoor Dry Unless Protected By Additional Means
- Number of Poles
- 3-Pole
- Phase
- Single Phase
- Type
- IP22 Angled Plug
- Wattage
- 7500
- Voltage Rating Description
- 125/250 VAC
- General Literature Asset 1 Display Text
- IEC Pin & Sleeve Devices
- General Literature Asset 3 Display Text
- PULP & PAPER SOLUTIONS
- Display Size
- Standard Sized
- Number Of Poles
- 3-Pole
- Style
- Standard Service
- Description - Invoice
- PS, IEC, PLUG, 3P4W, 30A 125/250V,LO-PRO
- Harmonization Code
- 8536694020
- MSDS Flag
- No
- Material - Mounting Hardware
- Cord Mounted
- Material
- Composite
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 7.200 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 10 EA
- Lowest Level UOM
- Each
Current / Amperage Rating30 A
PerformanceElectrical - Current Interrupting - Certified for current interruption at full rated current;Electrical - Dielectric Voltage - Withstands 3,000V AC;Electrical - Max Working Voltage - 250V RMS;Environmental - Flammability - HB or better per UL 94 or CSA C22.2 No. 0.17;Environmental - Ingress Protection - IP22 Suitability;Environmental - Operating Temperatures - Max. Continuous +75°C;Min. -40°C w/o impact;Mechanical - Impact Resistance - Per CSA C22.2 No. 182.1 / UL1682;Mechanical - Product Identification - Ratings are a permanent part of the device housing;Mechanical - Terminal Identification - Terminals identified in accordance with North American convention
ApplicationHigh Ampacity Connections
Cord TypeAll Portable
NEMA RatingNon-NEMA
Number of Wires4-Wire
Special FeaturesWatertight
Voltage Rating125/250 VAC
Wire Size#12 AWG to #10 AWG
Engineering Drawing 1 Display TextL430P12 AutoCAD Drawing
General Literature Asset 2 Display TextPulp & Paper Solutions
ConnectivityPressure Terminal Screws
Nema RatingNon-NEMA
Number Of Wires4-Wire
Class CodeA12
Freight Class Code06168002
Image Actual Or RepresentativeA
Sub Class CodeA12A180
Current Rating30 A
SeriesLow Profile
BOX SIZE5.245x21.625x9.995 (in)
Carton - Number of Sub Packs10
Carton - SCC-14 Next Lower Level Sub Pack783585888002
Each - Pack DescriptionEach
NAICS Code335931A104
