Hubbell Wiring Device-Kellems M4100C12R Heavy Duty Marine Grade Female Connector, 100A 125/250V, 3-Pole 4-Wire
Hubbell Wiring Device-Kellems M4100C12R Heavy Duty Marine Grade Female Connector, 100A 125/250V, 3-Pole 4-Wire
- MPN: M4100C12R
- UPC: 783585410036
- PPN: HBL-M4100C12R
- UNSPSC: 39121421
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$1752.20/ EA
Description
Heavy Duty Products, IEC Pin and Sleeve Devices, Marine Grade, Female, Connector Body, 100A 125/250V, 3-Pole 4- Wire Grounding, Terminal Screws, Yellow
Features
- Insulated non-metallic housing
- Self-closing gasketed cover
- Color coded housings for easy identification
- Reversed Service
Specifications
Specifications
- Country of Origin
- US
- Width
- 6.200 in
- Industry Standard(s)
- CSA Certified File LR280C;UL Classified to IEC 60309-1 IEC 60309-2;UL Listed, File E146033
- Amperage Rating
- 100 A
- Color
- Yellow
- Environmental Conditions
- Watertight
- NEMA Rating
- Non-NEMA
- Number of Poles
- 3-Pole
- Standard
- CSA Certified File LR280C;UL Classified to IEC 60309-1 IEC 60309-2;UL Listed, File E146033
- Type
- Watertight Connector Body
- Voltage Rating Description
- 125/250 VAC
- Display Size
- Standard
- Number Of Conductors
- 4-Wire Grounding
- Number Of Wires
- 4-Wire
- Class Code
- A12
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Sub Class Code
- A12A180
- Current Rating
- 100 A
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 28.800 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 6 EA
- Each - Pack Description
- Each
Current / Amperage Rating100 A
Each - Width6.200 in
PerformanceElectrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstand 3000V AC;Electrical - Max. Working Voltage - 600V RMS;Environmental - Flammability - HB or better per UL 94 or CSA C22.2 No. 0.17;Environmental - Ingress Protection - IP67 Suitability;Environmental - Moisture Resistance - Watertight per IEC 60309-1;Environmental - Operating Temperatures - Maximum Continuous 75°C;Minimum - 40°C w/o impact;Mechanical - Impact Resistance - Per CSA C22.2 No. 182.1 / UL1682;Mechanical - Product Identification - Ratings are a permanent part of the device housing;Mechanical - Terminal Identification - Terminals identified in accordance with North American and IEC conventions
ApplicationMarine Wiring Devices
Conductor Range#3 AWG to #1/0 AWG
InsulationInsulated Body
Number of Conductors4-Wire Grounding
Special FeaturesReversed Service
Temperature RatingMaximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact.
Voltage Rating125/250 VAC
ConnectivityPressure Terminal Screws
Nema RatingNon-NEMA
Number Of Poles3-Pole
StyleReverse Service
Description - InvoiceMARINE PS CONN, 3P4W 100A 125/250V
Harmonization Code8536694020
MSDS FlagNo
Material - Mounting HardwareCord Mounted
SeriesCorrosion Resistant
BOX SIZE13.000x16.600x14.600 (in)
Carton - Number of Sub Packs6
Carton - SCC-14 Next Lower Level Sub Pack783585410036
Case Weight18.980 lb.
Lowest Level UOMEach
Certifications
- EU RoHS Indicator
- Yes
