Balluff BNI IOL-752-V09-K007 IO-Link valve interface BNI IOL-752-V09-K007
- MPN: BNI IOL-752-V09-K007
- PPN: BAL-BNI006U
CAD
$413.28
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
You can use the advantages of IO-Link even with our valve interfaces. This is because decentrally installed valve terminals and the control level can easily be connected using these components.
Documentation & Downloads
Specifications
Key Specifications
| Version | Power Aux valve terminal connector |
|---|---|
| Interface | IO-Link 1.1 |
| Connection (COM 1) | M12x1-Male, 5-pin, A-coded |
| Outputs, number | 16 |
| Current sum UA, actuator | 1.2 A |
| Housing material | PA |
| Ambient temperature | -5-55 °C |
| Transfer rate | COM2 (38.4 kBaud) |
| Process data OUT | 2 bytes |
| Application | Festo with D-Sub female, 25-pin, GND on Pin 25, Bosch Rexroth LS04 |
|---|---|
| Operating voltage Ub | 18-30.2 VDC |
| Cable length L | 0.6 m |
| Output current max. UA, actuator | 400 mA |
| Function | 5-pin connection, Power Aux on Pin 2, also 0V on Pin 5 |
| Dimension | 53 x 61 x 12.5 mm |
| IP rating | IP40 plugged in |
| Process data cycle min. | 3.0 ms |
