Balluff BNI IOL-751-V08-K007 IO-Link Valve Interface, 24 Outputs, IP40 Rating, 18-30.2 VDC
- MPN: BNI IOL-751-V08-K007
- PPN: BAL-BNI006N
CAD
$386.49
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
IO-Link Valve Interface, 24 Outputs, IP40 Rating, 18-30.2 VDC
Documentation & Downloads
Specifications
Additional
- Outputs
- 24
- IP Rating
- IP40, plugged in
- Data Transfer Rate
- COM2 (38.4 kBaud)
- Cable Length
- 0.6 m
- Connection (COM 1)
- M12x1-Male, 5-pin, A-coded
- Interface
- IO-Link 1.1
- Housing Material
- PA
- Application
- Festo with D-Sub female, 25-pin, GND on Pin 25; Bosch Rexroth LS04; Bürkert Type 8640
- Country of Origin
- Germany
Operating Voltage18...30.2 VDC
Process Data Cycle Time Min.3.5 ms
Current Sum UA, Actuator4 A
Dimensions53 x 61 x 12.5 mm
Function4-pin connection; Power Aux on Pin 2
Process Data Out4 bytes
Ambient Temperature Range-5 to 55 °C
VersionPower Aux valve terminal connector
