Telemecanique Sensors 9007A NEMA limit switch, 9007C, low differential spring return rotary lever arm head
- MPN: 9007A
- UPC: 785901500889
- PPN: TES-9007A
- UNSPSC: 39122213
CAD
$101.72
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
These industrial heavy duty limit switches are applied in almost any environments. This replacement lever arm rotary limit switch head with low differential can be used on any of the 9007C bodies types. The limit switch head will actuate the snap action contacts when the lever arm in operated in the clockwise or counterclockwise direction. This limit switch head is NEMA 1, 2 4, 6, 6P, 12 and 13 rated when properly assembled to a 9007C body. It is also rated IP67. Limit switch head is UL listed and CSA certified. It weighs 0.19kg. It is compatible with 9007C limit switches. The 9007 series limit switches are designed to withstand harsh industrial environments and are available in a wide range of options.
Documentation & Downloads
Specifications
Key Specifications
| Type Of Approach | lateral approach, 1 or 2 programmable direction |
|---|---|
| Movement Of Operating Head | rotary |
| Associated Lever | 9007C |
| Type Of Operator | spring return without operating lever zinc low differential |
| Associated Body | 9007C |
| Device Short Name | 9007C |
| Series Name | heavy duty |
|---|---|
| Range Of Product | 9007 |
| Positive Opening | without |
| Product Or Component Type | limit switch head |
| Product Compatibility | 9007C |
| Head Type | rotary head |
Complementary
| Switch Actuation | CW and CCW || from left and right |
|---|
| Net Weight | 0.41 lb(US) |
|---|
Environment
| Ambient Air Temperature For Operation | -20-185 °F |
|---|---|
| Environmental Characteristic | standard environment |
| Ambient Air Temperature For Storage | -20-185 °F |
|---|
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| Rohs Exemption Information | Yes |
|---|---|
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Mercury Free | Yes |
|---|---|
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
