Telemecanique Sensors 9007AP321 Snap limit switch, 9007, 600 VAC 15amp ap +options

This product is part of the Nema Limit Switches range. This limit switch is a device that converts a mechanical motion into an electrical control signal. It has 1 NC and 1 NO, single pole double throw, double break, form Z, snap action contacts. It provides switch actuation by 30° cam. The limit switch has a spring return roller plunger and supports traverse approach in 2 directions. The movement of operating head is linear. It is a limit switch with a rated voltage of 600V AC and rated operating current of 15A. It is furnished with screw terminals for electrical connection. It is an IP20 and NEMA 1 rated product. This plunger head limit switch has a fixed body, made of cast zinc. Its dimensions are 21.08mm (width) x 68.33mm (depth) x 63.5mm (height). It weighs 0.05kg. It supports non oil tight panel mounting. The 9007 series limit switches are designed to withstand harsh industrial environments and are available in a wide range of options.
