Telemecanique Sensors XE2NP3131 Limit switch contact block, Limit switches XC Standard, 2 NO, slow break, simultaneous

MPN: XE2NP3131
PPN: TES-XE2NP3131
UNSPSC: 39121522

$61.73

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Limit switch contact block, Limit switches XC Standard, 2 NO, slow break, simultaneous

Documentation & Downloads

Specifications

Key Specifications

Series Name	standard format
Range Of Product	Telemecanique Limit switches XC Standard
Product Or Component Type	limit switch contact block
Device Short Name	XE2N

Contacts Type And Composition	2 NO
Contact Operation	slow-break, simultaneous
Associated Body	ZCT28
Number Of Poles	2

Complementary

Electrical Connection	screw-clamp terminals 1 x 0.5...2 x 2.5 mm²
Electrical Durability	5000000 cycles, DC-13 120 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C \|\| 5000000 cycles, DC-13 24 V, 13 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C \|\| 5000000 cycles, DC-13 48 V, 9 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Positive Opening	without
Contacts Insulation Form	Zb
Contact Code Designation	A300, AC-15 (Ue = 240 V), Ie = 3 A 10 A EN/IEC 60947-5-1 appendix A \|\| Q300, DC-13 (Ue = 250 V), Ie = 0.27 A EN/IEC 60947-5-1 appendix A
[Uimp] Rated Impulse Withstand Voltage	6 kV IEC 60664 \|\| 6 kV IEC 60947-1

[Ui] Rated Insulation Voltage	300 VUL 508 \|\| 500 V 3)IEC 60947-1 \|\| 300 VCSA C22.2 No 14
Short-Circuit Protection	10 A cartridge fuse gG
Minimum Actuation Speed	6 m/min
Contacts Material	silver plated contacts
Product Compatibility	XCKT
Maximum Resistance Across Terminals	25 mOhm IEC 60255-7 category 3

Offer Sustainability

Rohs Exemption Information	Yes
Environmental Disclosure	ENVPEP110614EN
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
California Proposition 65	WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Mercury Free	Yes
Sustainable Offer Status	Green Premium product
Reach Regulation	Free of Substances of Very High Concern above the threshold
Reach Free Of Svhc	Yes
