Schneider Electric LVCT01004S LV CT 1000 A - 0.333 V output - split core CT - 62 mm x 201 mm

LV CT 1000 A - 0.333 V output - split core CT - 62 mm x 201 mm
  • MPN: LVCT01004S
  • PPN: SCH-LVCT01004S

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$215.82/ EA

Description

This low-voltage split-core current transformer is part of PowerLogic BCPM (Branch Circuit Power Meter). It is Ideal for retrofit applications with Schneider Electric energy meters which accept low voltage current transducer input It is rated for a 1000A circuit. 0.333 V output, size 4. Split core opening is 62 mm x 201 mm.

Specifications

Environment

Ambient Air Temperature For Operation
-15-60 °C
Relative Humidity
95-95 %
Height
internal 139 mm || external 201 mm
Depth
30 mm
Ambient Air Temperature For Storage-40-70 °C
Widthinternal 62 mm || external 151 mm
Net Weight0.87 kg

Contractual warranty

Warranty
18 months

Offer Sustainability

China Rohs Regulation
X
Mercury Free
Yes
Eu Rohs Directive
Compliant
Reach Free Of Svhc
Yes
Rohs Exemption InformationYes
Toxic Heavy Metal FreeYes
Reach RegulationFree of Substances of Very High Concern above the threshold

Complementary

Measurement Accuracy
1 % 10...100 %
Range CompatibilityPowerLogic PowerLogic BCPM BCPMA multi-circuit energy meter || PowerLogic PowerLogic BCPM BCPMB multi-circuit energy meter || PowerLogic PowerLogic BCPM BCPME multi-circuit energy meter || PowerLogic PowerLogic BCPMSC BCPMSCA multi-circuit energy meter || PowerLogic PowerLogic BCPMSC BCPMSCB multi-circuit energy meter || PowerLogic PowerLogic BCPMSC BCPMSCE multi-circuit energy meter || PowerLogic PowerLogic EM3500 EM3502 energy meter || PowerLogic PowerLogic EM3500 EM3550 energy meter || PowerLogic PowerLogic EM3500 EM3555 energy meter || PowerLogic PowerLogic EM3500 EM3560 energy meter || PowerLogic PowerLogic EM3500 EM3561 energy meter || PowerLogic PowerLogic EM4200 EM4235 energy meter || PowerLogic PowerLogic EM4200 EM4236 energy meter || PowerLogic PowerLogic EM4900 EM4904 multi-circuit energy meter || PowerLogic PowerLogic EM4900 EM4908 multi-circuit energy meter || PowerLogic PowerLogic EM4900 EM4914 multi-circuit energy meter || PowerLogic PowerLogic EM4900 EM4928 multi-circuit energy meter || Acti 9 Acti9 iEM3000 iEM3455 energy meter || Acti 9 Acti9 iEM3000 iEM3465 energy meter

Specifications

Network Frequency
50/60 Hz
Electrical Connection
cable 1.8 m AWG 18) 600 V
Output Voltage
0.333 V
Current Transformer Type
split core balance
Device Short Name
LVCT
Product DestinationBCPM || BCPMSC || Enercept || iEM3000 || EM3500 || EM4200 || EM4900
Accessory / Separate Part Categorymeasurement accessory
[In] Rated Current1000 A
Product Or Component Typecurrent transformer
RangePowerLogic
