Schneider Electric LXM32MD85N4 Lexium 32 Motion Servo Drive, 85A, 9kW, IP20, Compact Design

  • MPN: LXM32MD85N4
  • PPN: SCH-LXM32MD85N4
  • UNSPSC: 39121021
  • If you can't find the product or are unsure which one you need, please use the Product Selector tool below
    • Available to Order

    Lead times may vary. For an accurate estimate please contact us.

    Available To Ship Immediately:0

    Loading dialog...

    Looking to buy a large quantity?

    To View Branch Inventory And Your Custom Pricing

    Spec sheet

    Description

    This product is part of the Lexium 32 range, an offer of motion servo drives for machines from 0.15kW to 7kW. The AC motion servo drive for one axis, features with an integrated EMC filter, compact drive with analogue inputs and pulse train. It provides 2 capture, 2 safety, 4 logic discrete inputs and 3 discrete outputs. Thanks to its compact design this servo drive enables to save on cabinet space and size, reduces the machine footprint and decreases costs. It is a motion servo drive with a rated supply voltage of 200V to 240V, 380V to 480V (three phase), a continuous output current of 32A at 4kHz and a continuous power of 1600W at 400V. It is furnished with terminal for electrical connection and RJ45 connector for Modbus integrated communication interface. CANopen, CANmotion, Ethernet/IP, EtherCAT, Profibus, DeviceNet possible with option card. It is an IP20 rated product. Its dimensions are 180mm (Width) x 240mm (Depth) x 385mm (Height). It weighs 9.6kg. This product is certified by CE, CSA, RoHS, TUV and UL. It meets EN/IEC 61800-3 and EN/IEC 61800-5-1 standards. This product is compatible with servo motor BMH. Servo drive range with four servo drive models and two servo motor families plus an intelligent selection of options. It provides you with the drive and motor combination that has exactly the right power, performance and functionality.

    Features

    • Lexium 32 range provides the drive and motor combinations for right power, performance and functionality
    • Three book-size servo drive models and two servo motor families plus a full range of intelligent options
    • Lexium 32 simplifies all aspects in the machine lifecycle from engineering to maintenance
    • A speed bandwidth of 1,600Hz provides outstanding response
    • Lexium 32 offers a host of features for rapid installation and maintenance with removable, colour-coded connectors
    • SoMove software for configuring on PC and transferring the configuration via Bluetooth or using a cable
    • Lexium 32 supports sercos/CANopen/CANmotion communication interfaces for fast integration into industrial architectures
    • Lexium 32 servo drives integrate Safe Torque Off safety function (IEC/EN 61800-5-2): shorter downtimes and less wiring
    • Optional enhanced safety module eases access to SS1, SS2, SOS and SLS safety functions, according to IEC/EN 61800-5-2

    Documentation & Downloads

    Specifications

    Key Specifications

    Country of OriginIndonesia
    Depth240 mm
    Weight10506 g

    Communications & Management Attributes

    Communication InterfaceModbus TCP, with separated communication card, CANopen, with separated communication card, CANmotion, with separated communication card, Ethernet/IP, with separated communication card, EtherCAT, with separated communication card, Profibus, with separated communication card, Profinet, with separated communication card, Analog I/O, with separated communication cardDigital I/O, Integrated

    Complementary Attributes

    Line Rated Current24.0 A
    Maximum Current Irms82.0 A
    Maximum Operational Altitude2000.0 m
    Us Rated Supply Voltage208 V380...480 V - 15...10 %
    Maximum Ambient Air Temperature For Operation50.0 °C
    Maximum Leakage Current30 mA
    Minimum Ambient Air Temperature For Operation0.0 °C
    Maximum In Rated Current24.0 A

    Important Information Attributes

    Persona Type IdsEU, OM, OM8
    Contact Bounce Time<= 1 ms compliment of STO_A, compliment of STO_B, <= 1 ms compliment of STO_A, compliment of STO_B<= 1 ms compliment of STO_A, compliment of STO_B, <= 1 ms compliment of STO_A, compliment of STO_B2 µs CAP0.25 µs...1.5 ms DI
    Control Signal Typepulse train output (PTO) RS422 <500 kHz <100 mpulse/direction (P/D), A/B, CW/CCW 5 V, 24 V link (open collector) <10 kHz <1 m, pulse/direction (P/D), A/B, CW/CCW 5 V, 24 V link (push-pull) <200 kHz <10 m, pulse/direction (P/D), A/B, CW/CCW RS422 <1000 kHz <100 m
    Electromagnetic Compatibilityconducted EMC, class A group 1 EN 55011, conducted EMC, class A group 2 EN 55011conducted EMC, environment 2 category C3 EN/IEC 61800-3, conducted EMC, category C2 EN/IEC 61800-3, susceptibility to electromagnetic fields, level 3 EN/IEC 61000-4-31.2/50 µs shock waves immunity test, level 3 EN/IEC 61000-4-5, electrical fast transient/burst immunity test, level 4 EN/IEC 61000-4-4, radiated EMC, class A group 2 EN 55011, radiated EMC, category C3 EN/IEC 61800-3
    Nominal Power9 kW 400 V 8 kHz, 5 kW 230 V 4 kHz, 9 kW 480 V 8 kHz
    Response Time<= 5 ms compliment of STO_A, compliment of STO_B, <= 5 ms compliment of STO_A, compliment of STO_B<= 5 ms compliment of STO_A, compliment of STO_B, <= 5 ms compliment of STO_A, compliment of STO_B
    Supply Voltage200-240 V three phase, 380-480 V three phase
    Tightening TorqueCN1 0.7-0.7 N.m, CN10 0.7-0.7 N.mCN8 3.8-3.8 N.m
    Carbon Footprint Of The Distribution Phase A415.518707806540371, 16 kg CO2 eq.
    Carbon Footprint Of The Installation Phase A5kg CO2 eq., 0
    Carbon Footprint Of The Use Phase B2 B3 B4 B6kg CO2 eq., 0
    Local Publishable Date2025-12-12
    Device TypeMotion - drive & motor
    TraceabilityYes
    Average Life Duration15 year(s)
    Weee ScopeIn
    Scope PerimeterAt least in Europe
    End Of Life Doc RefENVEOLI110605EN
    Reach Full Compliance Status IdCONTAINS_SVHC
    Rohs Eur In ScopeNo
    Rohs Eur Conformity Date1907
    China Rohs In ScopeYes
    With Recycled CardboardYes
    Product Contributes To Saved And Avoided EmissionsNo
    Tier2
    Function OptionAdvanced
    Market SegmentationIndustrial
    Braking Current50 mA
    Derating Altitude Scale90.0 m
    Device Short NameLXM32M
    Electrical Isolationbetween power and control
    Emc Filter Compatibilitytype 023
    Field Weakeningfalse
    MarkingCE
    Network Number Of Phases3
    Overvoltage CategoryIII
    Product AvailabilityNon-Stock - Not normally stocked in distribution facility
    Protection Typeagainst reverse polarity inputs signalagainst short-circuits outputs signal
    ReturnabilityNo
    Sampling Duration0.25 msDI 0.25 ms discrete
    Signalling Functiondisplay of faults 7 segments
    Status Led1 LED (Red) servo drive voltage
    Supply Voltage Limits323-528 V
    Switching Frequency4 kHz
    Type Of Cablesingle-strand IEC cable 50-50 °C) copper 90 °C XLPE/EPR
    Vibration Resistance1 gn (f= 13-150 Hz) conforming to EN/IEC 60068-2-61.5 mm peak to peak (f= 3-13 Hz) conforming to EN/IEC 60068-2-6
    Database Version2024-01
    Height Nominal385 mm
    Number Of Inputs/Outputs4 DI + 2 CI + 3 DO
    Customs Code8504404000
    Functional Unit DescriptionTo provide the phase currents required for the position control of the connected servo motors 100% of the time for 10 years up to 283W.To provide the phase currents required for the position control of the connected servo motors 100% of the time for 10 years up to 283W.
    Functional Unit Unitunit
    Recyclability Potential In %3
    Persona Type NamesEnd User, Original Equipment Manufacturer, OEM - Control Panelbuilder
    Continuous Power1600 W 400 V9000 W 230 V, 9000 W 480 V
    Electrical Connectionterminal 5 mm², 10 AWG CN1), terminal 5 mm², 10 AWG CN10), terminal 8 mm², 8 AWG CN8)
    Line Current3.5 A 88 % 380 V, with external line choke 2 mH, 2.9 A 98 % 480 V, with external line choke 2 mH, 3.6 A 174 % 480 V, without line choke19.9 A 145 % 480 V, without line choke
    Nominal Voltage208 V three phase, 400 V three phase, 480 V three phase
    Safety FunctionSTO (safe torque off), IntegratedSS1 (safe stop 1), with separated eSM safety card, SS2 (safe stop 2), with separated eSM safety card, SLS (safe limited speed), with separated eSM safety card
    Supply Voltage Descriptionthree phase 230 V, three phase 400 V
    Certificate AgencyCSA, TÜV, UL
    Carbon Footprint Of The End Of Life Phase C1 To C41.5162860807005318, 2 kg CO2 eq.
    Carbon Footprint Of The Manufacturing Phase A1 To A382 kg CO2 eq., 82.28580651037156
    Local Data StatusPublishable
    Return IndicatorN
    ServiceabilityYes
    Field Service DivisionIDIBS
    Weee ApplicabilityFinished product
    Weee Product Category5
    Eoli Availability DisplayYes
    Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
    Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
    Rohs Eur StatusCompliant By Exemption
    Rohs Eur Full Compliance StatusCompliant By Exemption
    China Rohs Label5
    Without Single Use PlasticNo
    Tier Id2
    Function Option IdADVANCED
    Market Segmentation IdINDUSTRIAL
    Product Kit IdentifierN
    Compatibility CodeLXM32M
    Derating Altitude Start1000.0 m
    Drive Voltage Drop Coefficient0.95
    Emc Filterintegrated
    Environmental Characteristicclasses 3C1 conforming to IEC 60721-3-3
    Format Of The Drivebook
    Network Frequency47.5...63 Hz
    Operating Positionvertical +/- 10 degree
    Phasethree phase
    Product Or Component Typemotion servo drive
    Range Of ProductLexium 32
    Safety LevelSIL 3 EN/IEC 61508PL = e ISO 13849-1
    Shock Resistance15 gn 11 ms EN/IEC 60028-2-27
    Software Versionv6.2.4
    Supply Frequency50/60 Hz - 5...5 %
    Sustainable PackagingYes
    Total Lifecycle Carbon Footprint99 kg CO2 eq.
    Type Of Coolingintegrated fan
    Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Data Sourceextrapolated product
    Width Nominal180 mm
    Nbr. Of Units In Pkg.1
    Warranty In Months18
    Functional Unit Quantity1
    Reference Lifetime In Y10

    Environment Attributes Main

    Ambient Air Temperature For Storage-25-70 °C, -25-70 °C
    Operating Altitude<= 3280.84 ft (1000 m) without derating, <= 3280.84 ft (1000 m) without derating, > 3280.84...9842.52 ft (> 1000...3000 m) with conditions, > 3280.84...9842.52 ft (> 1000...3000 m) with conditions<= 3280.84 ft (1000 m) without derating, <= 3280.84 ft (1000 m) without derating, > 3280.84...9842.52 ft (> 1000...3000 m) with conditions, > 3280.84...9842.52 ft (> 1000...3000 m) with conditions
    Take BackNo
    China Rohs RegulationX
    Carbon Footprint99.32080039761247
    Circularity ProfileENVEOLI110605EN
    Eu Rohs DirectiveCompliant By Exemption
    Packaging Without Single Use PlasticNo
    Relative HumidityClass 3K3 (5 to 85 %) without condensation IEC 60721-3-3
    Pep Verification Date2026-08-26
    Psr VersionPSR-0005-ed3-2023 06 06
    Ip Degree Of ProtectionIP20 conforming to EN/IEC 60529, IP20 conforming to EN/IEC 61800-5-1
    Product Compatibilityservo motor BMH 190 mm, 1, servo motor BMH 190 mm, 2, servo motor BMH 190 mm, 3, servo motor BMH 205 mm, 3
    Recycled Metal Content At Cr Level0 %
    Mercury FreeYes
    Ambient Air Temperature For Operation0-50 °C UL
    Environmental DisclosureENVPEP110705EN
    Packaging Made With Recycled CardboardYes
    Reach RegulationReference contains Substances of Very High Concern above the threshold
    Pep CodeENVPEP110705EN
    Pcr VersionPEP-PCR-ed4-2021 09 06
    Type Of Verification For The PepIndependent internal review

    General Attributes

    Phasethree phase
    Range Of ProductLexium 32
    Product Or Component Typemotion servo drive

    ETIM

    ETIM 8EC001857
    ETIM 10EC001857
    ETIM 9EC001857

    Output Attributes

    Discrete Output Voltage<= 30 V DC, <= 30 V DC<= 30 V DC, <= 30 V DC
    Output Voltage<= power supply voltage, <= power supply voltage
    Discrete Output Logicpositive or negative DO)EN/IEC 61131-2
    Discrete Output Typelogic DO)24 V DC
    Output Current 3s Peak82.0 A, 85 A 480 V 5 s
    Continuous Output Current32 A 4 kHz
    Discrete Output Number3
    Response Time On Output250 µs DO)discrete

    Contractual Warranty Attributes

    Warranty Period18 months
    Warranty18 months

    Input Attributes

    Discrete Input Logicpositive compliment of STO_A, compliment of STO_B)< 5 V > 15 V EN/IEC 61131-2 type 1, positive DI)> 19 V < 9 V EN/IEC 61131-2 type 1, positive or negative DI)< 5 V > 15 V EN/IEC 61131-2 type 1
    Discrete Input Voltage24 V DC capture, 24 V DC logic, 24 V DC safety
    Discrete Input Number2 capture, 2 safety4 logic
    Discrete Input Typecapture CAPlogic DIsafety compliment of STO_A, compliment of STO_B
    Lexium 32 Motion Servo Drive, 85A, 9kW, IP20, Compact Design
