Wiegmann B060604SC N12 JIC Screw-Cover 6X6X4 Carbon Steel - Gray
Wiegmann B060604SC N12 JIC Screw-Cover 6X6X4 Carbon Steel - Gray
- MPN: B060604SC
- UPC: 786725330553
- PPN: HBL-B060604SC
- UNSPSC: 39121324
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$171.28/ EA
Description
N12 JIC Screw-Cover 6X6X4 Carbon Steel - Gray
Features
- Bodies and doors fabricated from 14 gauge steel. Continuously welded seams ground smooth, less knockouts of holes. Lids are sealed with closed cell oil resistant neoprene gasket. External mounting plates, top and bottom of enclosure. Weldnuts are provided to secure optional back panel. Captivated cover screws are provided which thread into sealed wells to prevent leakage through cover. Grounding provisions provided.
Specifications
Specifications
- Buy American Compliant
- Contact Manufacturer
- Each - Width
- 7.400 in
- Color
- Ansi-61 Gray Textured
- Cubic Capacity
- 144 cu.in
- Finish
- Textured
- Mounting
- External Mounting Plates
- Standard
- cULus
- Width
- 6 in
- Finish Type
- Textured
- Mounting Type
- External Mounting Plates
- ARRA Compliant
- Contact Manufacturer
- Description - Invoice
- JIC,CS,SCREW COVER,6X6X4
- Harmonization Code
- 7326908688
- Lead Time
- 7 wk
- Order Multiple
- 1 EA
- Stock Indicator
- S - Shelf Stock
- UL Listed
- Yes
- Material
- Carbon Steel
- BOX SIZE
- 4.750x8.600x7.400 (in)
- Carton - Number of Sub Packs
- 1
- Carton - SCC-14 Next Lower Level Sub Pack
- 00786725330553
- Pallet Height
- 47.250 in
- Pallet Weight
- 860.625 lb.
Country of OriginMX
ApplicationDesigned for use as instrument housings, electrical control enclosures, terminal wiring boxes, or electrical junction boxes. Provides protection from dirt, dust, oil, and water.
Cover TypeScrew Cover
Depth4 in
Height6 in
NEMA Rating12
TypeEnclosure
Weight4.9 lb.
Material typeCarbon Steel
Nema Rating12
Class CodeP04
Freight Class Code06316009
Image Actual Or RepresentativeR
MSDS FlagNo
Returnable IndicatorYes
Sub Class CodeP04P067
ConstructionContinuously Welded Seams
Base Unit of MeasureEA
Carton - Gross Weight per Pack4.900 lb.
Carton - Pack DescriptionCarton
Carton - Total Units1 EA
Pallet Length40.000 in
Pallet Width48.000 in
Certifications
- Certified Listed
- cULus
- Listings
- UL, CSA
EU RoHS IndicatorYes
