Wiegmann N412161608C N412 Single Door Wall-Mount Ultimate 16X16X8 Carbon Steel - Gray
- MPN: N412161608C
- UPC: 786725859054
- PPN: HBL-N412161608C
- UNSPSC: 39121324
CAD
$824.25
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
N412 Single Door Wall-Mount Ultimate 16X16X8 Carbon Steel - Gray
Features
- Hubbell Wiegmann N12C ULTIMATE Series Enclosures are designed to house and protect electrical and electronic components from harsh, dirty environments
- For use in installations where dirt, dust, oil, water or other contaminants are present
- Streamlined styling, flush latching and attrative durable finish complement any high tech electronic equipment.
Documentation & Downloads
Specifications
Key Specifications
- Cubic Capacity
- 2048 cu.in
- Mounting
- Mounting Holes
- Standard
- cULus;IEC 60529
- ARRA Compliant
- Contact Manufacturer
- Country of Origin
- Mexico
- Actual Width
- 16.06 in
- Depth
- 8 in
- Industry Standard(s)
- cULus;IEC 60529
- Weight
- 27 lb.
- Engineering Drawing 3 Display Text
- MOD Center Drawings Instructions
- Cable Entry
- NO
- Finish Type
- Smooth
- Material type
- Carbon Steel
- Nema Rating
- 1,3R, 12, 13, 4
- Type
- Enclosure
- Description - Invoice
- N412,SD,16X16X8,CONCEPT
- Harmonization Code
- 7326909999
- Lead Time
- 21 wk
- Order Multiple
- 1 EA
- Sub Class Code
- P02P038
- UL Listed
- Yes
- Material
- Carbon Steel
- BOX SIZE
- 10.650x19.550x17.050 (in)
- Carton - Number of Sub Packs
- 1
- Carton - SCC-14 Next Lower Level Sub Pack
- 00786725859054
- Pallet Height
- 47.100 in
- Pallet Weight
- 378.600 lb.
- NAICS Code
- 3359326101
FinishSmooth
NEMA Rating1,3R, 12, 13, 4
Sub BrandUltimate Series
Stock IndicatorS - Shelf Stock
Actual Depth9.75 in
ColorANSI-61 Gray, Textured
Height16 in
Number of Doors (Fixed)1
Width16 in
ApplicationHubbell Wiegmann N412C ULTIMATE Series Enclosures are designed to house and protect electrical and electronic components from harsh, dirty environments. For use in installations where dirt, dust, oil, water, or other contaminants are present. Streamlined
Cover TypeDoor
KnockoutsNo
Mounting TypeMounting Holes
Number of Holes4
Class CodeP02
Freight Class Code06316009
Image Actual Or RepresentativeR
MSDS FlagNo
Returnable IndicatorYes
Latches Type1/4 Turn
ConstructionContinuously Welded Seams
Base Unit of MeasureEA
Carton - Gross Weight per Pack27.000 lb.
Carton - Pack DescriptionCarton
Carton - Total Units1 EA
Pallet Length48.000 in
Pallet Width40.000 in
Certifications
- Buy American Compliant
- Contact Manufacturer
- cULus
- YES
- Certified Listed
- cULus;IEC
- Listings
- cULus;IEC 60529
CSA ApprovedNO
ETLNO
EU RoHS IndicatorYes
