Schneider Electric MH32 NEMA 1 Enclosure Box, 20 Inch W x 32 Inch H x 5.75 Inch D, Steel

MPN: MH32
UPC: 785901027812
PPN: SCH-MH32

$140.10

Available to Order

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

NQ and NF Panelboards applications include commercial buildings, industrial buildings, data centers, stadiums, and offices. NQ and NF Panelboards are versatile panelboards that feature a wide selection of circuit breakers, accessories, and ready to install kits. These panelboards have many different options for your enclosure box and its accessories. This enclosure box is rated as a Type 1 with one blank end wall and one end wall with knockouts for common conduit sizes. The enclosure dimensions are 20 inch width x 32 inch height x 5.75 inch depth. NQ and NF enclosures are UL listed for use in the USA and Canada. The end walls of NF and NQ enclosures are removable to simplify field modification to support the widest range of electrical conduit connections. NC trim fronts for interiors rated up to 250A may be screwed directly to the deadfront of the NF or NQ panelboard. NC trim fronts for interiors rated 400A or greater are vented and designed to be screwed directly to the Type 1, 2 enclosure of the NF or NQ panelboard. MHxxWP enclosures provide Type 3R/5/12 protection to NF and NQ Panelboards, and are supplied with removable blank end walls. MHxxBE and MHxxD9 Type 1 enclosures are supplied with removable blank end walls at both ends. MHxx enclosures have one blank end wall and one end wall with knockouts for common conduit sizes.

Features

Specifically engineered as the rugged outer shell for Schneider Electric NQ and NF panelboards, this 32-inch high MH-type enclosure ensures a precise, factory-matched fit. For contractors and industrial electricians, this means a seamless "slide-in" installation of the interior bus bar assembly, reducing labor time and ensuring the finished distribution panel meets exact OEM tolerances.
Constructed from heavy-duty, galvanized sheet steel, this enclosure provides a secure, protective barrier against dust, light debris, and accidental contact in indoor settings. It is the industry standard for electrical rooms, mechanical closets, and commercial warehouses, offering a professional, durable housing that protects sensitive circuit breakers and wiring from environmental interference.
Designed to be paired with a lockable trim and door assembly (sold separately), this box provides a secure enclosure that prevents tampering or accidental switching of critical circuits. This added layer of physical security is vital for public spaces, schools, and multi-family residential buildings where maintaining control over the power distribution system is a primary safety concern.
Fully UL Listed and CSA Certified, this MH32 box is manufactured to the highest North American safety standards for electrical cabinetry. Using a certified Schneider enclosure ensures your installation passes rigorous local inspections and provides peace of mind that the housing can withstand the thermal and mechanical stresses of a high-capacity power system.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	United States

Depth	5.75 in

Complementary Attributes

Line Rated Current	225 A

Important Information Attributes

Persona Type Ids	EU, LC, OM
Carbon Footprint Of The Distribution Phase [A4]	5.771089910770677, 6 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]	0.00001113966551076819, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]	kg CO2 eq., 0
Local Publishable Date	2026-03-26
Stocking Flag	N
Weee Scope	Out
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	2532
China Rohs In Scope	No
With Recycled Cardboard	No
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Market Segmentation	Commercial
Enclosure Material	steel
Product Availability	Stock - Normally stocked in distribution facility
Returnability	Yes
Sustainable Packaging	No
Pep Code	ENVPEP2510012EN
Pep Verification Date	2025-11-01
Psr Version	PSR-0005-ed3.1-EN-2023 12 08
Data Source	extrapolated product
Functional-unit Quantity	1
Reference Lifetime In Y	20
Energy Model - Installation [A5]	No energy used
Energy Model - End Of Life [C1-c4]	Global, European and French datasets are used.
Height Nominal	32 in
Certificate Agency	cULus
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8538100000

Persona Type Names	End User, Contractor, Original Equipment Manufacturer
Carbon Footprint Of The End-of-life Phase [C1 To C4]	16 kg CO2 eq., 16.35556336691456
Carbon Footprint Of The Manufacturing Phase [A1 To A3]	69 kg CO2 eq., 68.59190217696786
Local Data Status	Publishable
Return Indicator	Y
Stock Policy	2
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	1
Function Option Id	STANDARD
Market Segmentation Id	COMMERCIAL
Product Kit Identifier	N
Energy Efficiency Optimized	False
Product Or Component Type	enclosure
Software Version	v6.2.5-6
Total Lifecycle Carbon Footprint	91 kg CO2 eq.
Database Version	2024-01
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
Functional-unit Description	Protect people from direct contact with live active parts and ensure the grouping of control, command and protection devices in a single enclosure or cabinet having the following dimensions H x L x D or an assembly of X enclosures or cabinets having the following dimensions H x L x D, with rated current In, while protecting them against mechanical impacts (IK) and the penetration of solid objects and liquids (IP), according to the appropriate use scenario, and for the reference service life of the product of 20 years.
Functional-unit Unit	unit
Energy Model - Manufacturing [A1-a3]	Electricity Mix; Low voltage; 2020; Mexico, MX
Energy Model - Use [B6]	Electricity origin
Recyclability Potential In %	97
Width Nominal	20 in
[Ue] Rated Operational Voltage	600 V AC48 V DC
Package Weight(Lbs)	10.954 kg
Warranty (In Months)	18

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Reach Free Shvc	Yes
Toxic Heavy Metal Free	Yes
Carbon Footprint	90.71856659431862
Eu Rohs Directive	Compliant
Packaging Made With Recycled Cardboard	No
Reach Free Of Svhc	Yes
Pep Code	ENVPEP2510012EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review

Take Back	No
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP2510012EN
Nema Degree Of Protection	NEMA 1
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2025-11-01
Psr Version	PSR-0005-ed3.1-EN-2023 12 08
