Burndy YA392LN HYLUGTM Tin Plated Terminal Connector, 750 kcmil, 1/2 Inch Stud, 600V-35kV
- MPN: YA392LN
- UPC: 781810522073
- PPN: BUR-510207
CAD
$142.86
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Cu Comp Terminal Code Cond, Bvl Entry, 2 Hole/W/InspWindow, 750 kcmil Str Code, 600 V-35 kV, 1/2" Stud, 1.75" Spacing, Std bbl, Tin Plated, Black, 24 Index.
Documentation & Downloads
Specifications
Dimensions
- Dimension - B Length fraction
- 1-7/16 in
- Dimension - Bolt Hole Size inch
- 0.52 in
- Dimension - D inch
- 3.02 in
- Dimension - L Length Overall mm
- 136 mm
- Dimension - N inch
- 0.63 in
- Dimension - Pad Width inch
- 1.91 in
- Dimension - Stud Size inch
- 1/2
- Physical Attribute - Tongue Angle
- Straight
Dimension - B Length inch1.42 in
Dimension - Bolt Size fraction1/2
Dimension - Hole Size mm14 mm
Dimension - Length Overall inch5.36 in
Dimension - Outside Diameter inch1.30 in
Dimension - Strip Length inch1-15/16
Dimension - Z inch0.64 in
Certifications and Compliance
- Certification - CSA Approved
- Yes
- Certification - UL Recognized
- No
- Standards - RoHS Compliance Status
- CM
Certification - ETLNo
Certification - cULusNo
UL ListedYes
Conductor Related
- Conductor - Copper DLO Size Range
- N/A
- Conductor - Copper Str Size Range
- 750 kcmil
Conductor - Copper Str Size750 kcmil
Conductor - MaterialCopper
General
- Application
- For Code Conductor
- Connector Type
- Terminal
- Feature - Barrel Type
- Standard
- Physical Attribute - Number of Holes
- 2
- Plated
- Y
- Sub Brand
- HYLUG
- Type
- Standard Barrel, Tin Plated
Color CodeBlack
Die Index24
MaterialCopper
Physical Attribute - Tongue TypeStandard
Plating TypeTin - Electro Plated
Trade NameHYLUG™
UPC781810522073
Electrical Ratings
- Rating - KVA
- 35 kV
- Voltage - Maximum
- 35000
Rating - Minimum Voltage600
Logistics
- Minimum Pack Quantity
- 1
