ILSCO GBL-4DBTH-14 Permaground Copper Lay-in Groud Lug, Conductor Size 4-14, 1/4 Bolt Size, Hex Head, Tin Plated
- MPN: GBL-4DBTH-14
- UPC: 783669960273
- PPN: ILC-GBL-4DBTH-14
CAD
$21.35
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Permaground Copper Lay-in Groud Lug, Conductor Size 4-14, 1/4 Bolt Size, Hex Head, Tin Plated
Documentation & Downloads
Specifications
Key Specifications
| Height | 0.965 in | 24.511 mm |
|---|---|
| Weight | 0.0848683950294886 lbs |
| Length | 1.194 in | 30.3276 mm |
|---|---|
| Width | 0.472 in | 11.9888 mm |
Dimensions
| Dimension G (IN) | 0.21 |
|---|---|
| Drive Size Main | 7/16 |
| Height BX (IN) | 2.25 |
| Length (mm) | 30.3276 |
| Mounting Hole Diameter (mm) | 6.731 |
| Tang Length (mm) | 11.938 |
| Tang Thickness (mm) | 4.699 |
| Tang Width (mm) | 11.9888 |
| Width BX (IN) | 5 |
| Dimension G (mm) | 5.334 |
|---|---|
| Drive Type Main | External Hex |
| Height (mm) | 24.511 |
| Mounting Hole Diameter (IN) | 0.265 |
| Tang Length (IN) | 0.47 |
| Tang Thickness (IN) | 0.185 |
| Tang Width (IN) | 0.472 |
| Weight BX (LB) | 4.3 |
| Width (mm) | 11.9888 |
Testing Standards
| CSA File Number | LR-29601 |
|---|---|
| Prop65 Compliance | WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov |
| UL / CULUS Specification | UL 2703 Listed, UL 467 Listed |
| CSA Standard | C22.2 No. 65-03 |
|---|---|
| UL Control Number | 667P |
| UL File Number | E354420 Vol. 2, E34440 |
Additional Class Attributes
| Connection | Mechanical |
|---|---|
| Mounting Kit Hardware Part # | GBL-MH3 |
| Number of Mounting Holes | 1 |
| Mounting Hole Type | Thru |
|---|---|
| Number of Conductors | 1 |
| Number of Ports / Wireways | 1 |
Material and Finish
| Conductor Material | Copper |
|---|---|
| Material | Copper |
| Wire Binding Hardware Material | Stainless steel |
| Connector Finish | Tin |
|---|---|
| Wire Binding Hardware Finish | Nickel Strick, Zinc, Green Dye |
Conductor Ranges
| Conductor Range CU Solid (Primary, run, main, line) | 10 Sol - 14 Sol |
|---|
| Conductor Range CU Stranded (Primary, run, main, line) | 4 Str - 14 Str |
|---|
Additional Technical Specifications
| Conductor Type | Stranded, Solid |
|---|
General
| Bag Quantity | 1 |
|---|---|
| Direct Burial | Yes |
| NEMA Code | S-573-2 |
| Carton Quantity Description | STD PACK QTY 50 |
|---|---|
| Dual Rated | No |
| UPC Code | 78366996027 |
Bolt and Screw Sizes
| Mounting Bolt/Stud Size | 1/4 |
|---|---|
| Wire Binding Screw Size | 1/4 |
| Number of Wire Binding Screws per Port | 1 |
|---|---|
| Wire Binding Torque | 2 AWG = 40, 8 AWG = 25, 10 - 18 AWG = 20, 4 - 6 AWG = 35 |
