Leviton PE500-D0E 0-10V Reverse Phase Power Extender, 450W @ 120V, 1,000W @ 277V, Plenum Rated
- MPN: PE500-D0E
- UPC: 078477775882
- PPN: LEV-PE500-D0E
CAD
$1305.39
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
0-10V to 0-120/277 Reverse Phase Power Extender
Features
- Converts 0-10V sinking control signals to 120/277V reverse phase control
- Direct J-box mountable
- 120V and 277V compatible
- Auto-sensing voltage switch
- 450W @ 120V, 1,000W @ 277V
- Plenum rated
- One PE500 per fixture run
- Technical information:
- Electrical Specifications: Power Rating: 450W Max @ 110-120V, 1,000W Max @ 277V; Max Current to Dimmer: 7mA; Max Fixture Run Length: Calculate maximum run per PE500 unit based on the power consumption of the fixture used; Operating Voltage: 110VAC-120VAC, 277VAC auto-sensing voltage switch; Operating Hertz: 60Hz
- Control: Dimming: 110-120VAC; ELV - RP; converted from 0-10VDC controller, 277VAC; ELV - RP; converted from 0-10VDC controller
- Physical: Dimensions: 3.4” (87mm ) W x 2” (50mm ) H x 7” (178mm) L; Housing/Lens: Injection molded polycarbonate ; Connectors: Lead wire 6” from conduit; Weight: 0.99lbs (0.45kg); Environment: ETL damp location; Mounting: Conduit mounting for both sides
- Environment: Startup and Operating Temperature: -4 - 104°F (-20 - 40°C); Storage Temperature: -40 - 176°F (-40 - 80°C)
- ETL/cETL damp locations
- RoHS compliant
- Warranty: The manufacturer warrants that, for two years from the date of shipment to Customer, each PE500 will be free from any defects in materials and workmanship which causes the product to fail to operate in accordance with the products’ performance specifications as they exist at the time of shipment, as long as it is used with LED Lighting fixtures with a Power Factor of > 0.9 and a THD of 20% or less.
- The Leviton 0-10V Reverse Phase Power Extender (PE500) converts a 0-10V dimming signal to control a fixed line voltage output. One PE500 is used per fixture run up to the maximum wattage of 450W with a 120V load and up to 1,000W on a 277V load. The PE500 mounts directly into a junction box and is plenum rated for easy installation.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- China
RoHS CompliantFalse
Standards and Certifications
- Buy American Act (BAA) Compliant
- Yes
Mechanical Specifications
- Neutral Wire Connection
- Required
Product Features
- Color
- Gray
- Sensor Type
- Power Pack
Product LinePE500
Electrical Specifications
- Frequency
- 60Hz
Voltage110-120 VAC 277 VAC
