Harmony 9001K Red Mushroom Push Button 35mm, Spring Return, 1 NC
Schneider Electric

Schneider Electric 9001KR24RH6 Harmony 9001K Red Mushroom Push Button 35mm, Spring Return, 1 NC

  • MPN: 9001KR24RH6
  • UPC: 785901033516
  • PPN: SCH-9001KR24RH6
  • If you can't find the product or are unsure which one you need, please use the Product Selector tool below
  • CAD

    $158.12

    / EA

    Available to Order

    Lead times may vary. For an accurate estimate please contact us.

    Company Stock:

    0

    Looking to buy a large quantity?

    To view product inventory

    Spec sheet

    Description

    This Harmony 9001K, modular red push button has 2 positions, operates with spring return mechanism. It has a chromium-plated metal bezel, a round shape and 35mm mushroom head and 1 x NC contact. This 35mm mushroom shaped push button head is ideal for situations where quick actions are required for a process or machine to function correctly or where operator movements require maximum ergonomy. It is easily combined with Harmony range of contact blocks to perform a large variety of control functions. It is clearly distinguishable visually at a distance thanks to a prominent mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant metal bezel and body ensures product continues to operate even after severe accidents.

    Documentation & Downloads

    Specifications

    Key Specifications

    Operator Additional Information
    screw-on plastic with set screw
    Operator Profile
    red mushroom Ø 35 mm
    Product Or Component Type
    push-button
    Range Of ProductHarmony 9001K
    Type Of Operatorspring return
    Device Short NameK

    Complementary

    Contacts Type And Composition
    1 NC
    Bezel Material
    metal
    Connections - Terminals
    screw clamp terminals
    Light Block Supply
    without supply
    Operator Profile
    mushroom Ø 35 mm
    Operating Position
    any position
    Size
    30 mm
    Light Sourcewithout
    [Ie] Rated Operational Current10 A, AC-15 || 10 A, DC-13
    Contact Operationstandard
    Mounting Diameter30 mm
    Type Of Operatorspring return
    Cap/Operator Or Lens Colourred
    Device Presentationcomplete product

    Offer Sustainability

    China Rohs Regulation
    X
    Rohs Exemption Information
    Yes
    Environmental Disclosure
    ENVPEP121006EN
    Eu Rohs Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    Weee
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
    Circularity ProfileN/A
    Mercury FreeYes
    Sustainable Offer StatusGreen Premium product
    Reach RegulationReference contains Substances of Very High Concern above the threshold

    Environment

    Product Certifications
    NEMA || UL listed file E42259 CCN NKCR || CSA LR 25490 class 3211 03 || CE
    Nema Degree Of ProtectionNEMA 1/2/3/3R/4/6/12/13
