Ideal Industries 85-345 6P6C RJ-11 Modular Plugs - 25 Pack for 1-3 Line Systems
- MPN: 85-345
- UPC: 783250853458
- PPN: IDL-85-345
CAD
$20.58
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
The six position RJ-11 style modular plug is traditionally used in voice/phone applications. Two versions are available: 6P6C (six position/six contact) and 6P4C (six position/four contact). The RJ-11 6P4C (four contacts) is used for 1 or 2 line phone systems common in residential systems. The RJ-12 6P6C (six contacts) is used for 1, 2, or 3 line systems and is found in more commercial systems. Modular plug connectors support the latest TIA/EIA standards for twisted pair cabling. IDEAL modular plugs are designed to work seamlessly with the IDEAL Telemaster™ series of modular plug crimp tools. Plugs are designed and manufactured to support all 100Ω cable wiring schemes.
Features
- 6 position, 6 contact RJ-11 modular plug for Cat 3/5e and traditional phone wire
- 50 micro-inch gold plating on contact mating area for long term reliability in connectivity, even after hundreds of mating cycles
- Complies with industry standard mechanical and electrical specifications for compatibility with compliant telephone jacks and ports
- Designed to work seamlessly with IDEAL Telemaster™ crimping tools. Also compatible with industry standard modular plug crimping tools meeting specifications.
- Use with 1, 2, or 3 line phone systems
- Three prong contact design for use with solid or stranded 24-26 AWG insulated copper conductors
- Permanent connection - once crimped they cannot be reused
- Primary strain relief supports to retain cable jacket and minimize conductor movement once crimped
- Non feed through design to prevent external conductor/device shorting and RF signal leakage
