Schmersal 101195136 White LED Light Terminal Block, 10 mm Width, 46 mm Length, 24 VAC/DC
- MPN: 101195136
- PPN: SCM-101195136
CAD
$129.88
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
White LED Light Terminal Block, 10 mm Width, 46 mm Length, 24 VAC/DC
Specifications
Key Specifications
| Length | 46 mm |
|---|---|
| Depth | 45 mm |
| Width | 10 mm |
|---|
Mechanical data - Dimensions
| Width | 10 mm |
|---|
| Depth | 45 mm |
|---|
Ambient conditions - Insulation values
| Rated insulation voltage U | 440 V |
|---|
| Degree of pollution | 3 |
|---|
General data - Features
| Integral system diagnostics, general | Yes |
|---|
General data
| Standards | EN IEC 60947-5-1 | EN IEC 60947-1 |
|---|---|
| Installation conditions (mechanical) | arbitrarily |
| Gross weight | 23 g |
| Climatic stress | IEC 60068-2-30 |
|---|---|
| Enclosure material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
Ambient conditions
| Degree of protection of clips or terminals | IP20 |
|---|---|
| Resistance to vibrations | 5 g |
| Resistant to vibration | 20 g / 10 ... 150 Hz |
| Ambient temperature | -25 ... +75 °C |
|---|---|
| Restistance to shock | 30 g / 18 ms |
Mechanical data - Connection technique
| Termination | Screw terminals M20 x 1.5 |
|---|---|
| Cable section, minimum | 0.5 mm², rigid | 0.5 mm², flexible |
| Tightening torque of Clips | 1 Nm |
| Terminal designations | EN 50005 | EN 50013 |
|---|---|
| Cable section, maximum | 2.5 mm², rigid | 1.5 mm², flexible |
Mechanical data
| Installation instructions | pluggable |
|---|
| Mounting flange position | 3 |
|---|
Approvals - Standards
| Certificates | cURus |
|---|
Status indication
| Colour of the LED | White |
|---|
| Note (LED switching conditions display) | Supply voltage UB: 24 VAC/DC |
|---|
