Pass & Seymour PS45FRBR 45° Red Double Set Screw Panel Mount Female, 2.25 Inch Width, UL & CSA Listed
Pass & Seymour PS45FRBR 45° Red Double Set Screw Panel Mount Female, 2.25 Inch Width, UL & CSA Listed
- MPN: PS45FRBR
- UPC: 785007033823
- PPN: P-S-PS45FRBR
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$80.62/ EA
Description
Pass and Seymour cam-type devices are built with top-quality materials for enhanced durability and service life, along with increased insulation protection for safety. Our angled receptacle offerings are ideal for supplying temporary electrical distribution for film and other entertainment production, theme parks, fairs, carnivals, concert venues, arenas and convention centers, mining and construction, marine shipbuilding and repair and more.
Features
- Type 3R Rated for indoor and outdoor use.
- Solid one-piece brass contacts provide superior and consistent connection under the most extreme conditions.
- Housing is made of Santoprene: for outstanding impact and chemical resistance.
- Intermateable and compatible with competitive cam-type products.
- Can be retrofitted to existing locations and power distribution systems.
- Brass eyelets for #10-32 mounting through bolts (bolts not provided).
- For covering patents, see www.legrand.us/patents.
Specifications
Specifications
- Width
- 2.25 in
- Country of Origin
- Mexico
- Voltage
- 600.0 V
- Standard
- UL Listed
- Standard
- CSA Listed
- Special Features
- Cam-Type Devices are built with topquality materials for enhanced durability and service life, with increased insulation protection for safety. They are designed and engineered for interchangeability with other manufacturers' cam-type products. With their uncompromising construction and performance, P&S Cam-Type Devices are the worry-free choice for arenas and convention centers, concert venues, movie and other entertainment production, mining and construction, shipping, airports, and many other portable/ temporary power applications.
Product LinePass & Seymour
Environmental ConditionsEnvironmental Flammability UL94 V2 Operating Temperature Maximum continuous +75°C, minimum -40°C without impact Enclosure NEMA Type 3R and 4
Amperage400.0 A
NEMA RatingNEMA 3R
Wire Size2/0 - 4/0
