Balluff BNI IOL-730-002-E023 Signal Converter 18 x 135.5 mm, M12x1 Connection, IP67, 16 Bit
- MPN: BNI IOL-730-002-E023
- PPN: BAL-BNI00C6
CAD
$400.84
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Signal Converter 18 x 135.5 mm, M12x1 Connection, IP67, 16 Bit
Documentation & Downloads
Specifications
Additional
| Operating Voltage | 18...30.2 VDC |
|---|---|
| IP Rating | IP67, when threaded in |
| Ambient Temperature | -5...70 C |
| Connection | M12x1-Male, 4-pin, A-coded |
| Configurable Inputs/Outputs | yes |
| Analog Inputs | Voltage / Current / Temperature (0-10 V / -10-10 V / 0-5 V / -5-5 V / 5-10 V / 4-20 mA / 0-20 mA / Pt100 / Pt1000 / Type J / Type K) |
| Process Data In | 3 bytes |
| Data Transfer Rate | COM2 (38.4 kBaud) |
| Country of Origin | Hungary |
| Resolution | 16 Bit |
|---|---|
| Process Data Cycle Min. | 10 ms |
| Dimension | 18 x 135.5 mm |
| Housing Material | 1.4404 stainless steel; PTFE |
| Analog Outputs | 0-10 V / -10-10 V / 0-5 V / -5-5 V / 5-10 V / 4-20 mA / 0-20 mA |
| Process Data Out | 2 bytes |
| Interface | IO-Link 1.1 |
| Approval/Conformity | CE; UKCA; WEEE |
