Spotlight Ø 30 x 67.5 mm, LED White Light, IP67, 1200 Lux
Balluff

Balluff BAE LX-VS-SW030A Spotlight Ø 30 x 67.5 mm, LED White Light, IP67, 1200 Lux

  • MPN: BAE LX-VS-SW030A
  • PPN: BAL-BAE011M

CAD

$1382.28

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Company Stock:

0

Looking to buy a large quantity?

To view product inventory

Spec sheet

Description

Illuminate your workspace with the precision-engineered Balluff spotlight, designed for optimal performance in demanding environments. With a compact size of Ø 30 x 67.5 mm, this LED spotlight delivers an impressive brightness of 1200 Lux at a distance of 0.1 meters, and can reach up to 200,000 Lux in boost mode, making it ideal for various applications. Built to withstand the rigors of industrial use, it boasts an IP67 rating for dust and water resistance, ensuring reliable operation in challenging conditions. Its robust construction features high-quality materials, including stainless steel and brass, while the 10° beam angle focuses light where you need it most. With a maximum current draw of 300 mA and a rated operating voltage of 24 V DC, this spotlight is not only efficient but also designed for continuous operation, making it a versatile addition to your lighting solutions.

Documentation & Downloads

Specifications

Additional

Current
300 mA
Illuminance
1200 Lux; 200000 Lux (Boost mode)
Dimension
8 30 x 67.5 mm
Operating Temperature Range
-10 to 50 6 C
Material
1.4301 stainless steel; Brass; PC
Approval
CE; UKCA; WEEE
Digital Inputs
Trigger
Operating Mode
Normal (continuous operation); Boost (continuous operation with cooling)
Voltage24 V DC
Beam Angle10 6
Illumination Aread8 25 mm
ConnectionCable with connector, M12x1-Male, 4-pin, 0.3 m
IP RatingIP67
Country of OriginGermany
VersionSpotlight
