Telemecanique Sensors SM650A68000 Hyde Park, Ultrasonic sensor, discrete, 18 mm barrel, 12 24 V DC
Telemecanique Sensors SM650A68000 Hyde Park, Ultrasonic sensor, discrete, 18 mm barrel, 12 24 V DC
- MPN: SM650A68000
- UPC: 785901980681
- PPN: TES-SM650A68000
- UNSPSC: 39122230
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$824.58/ EA
Description
This SM600 Series SUPERPROX® Ultrasonic Proximity Sensor is part of the Hyde Park Ultrasonic Sensors product range. The SM600 applications include sensing metal parts as close as 1in (25mm), cap presence and tilt detection, fill level checking, fill tube presence monitoring, downed container and container edge detection, and case inspection. The sensor is a self contained, pulse-echo device that both transmits and receives sonic energy over a 6in (152mm) sensing range with fixed sensing window from 1in (25mm) to 6in (152mm). The response time is 5ms. The sensor accepts 12VDC to 24VDC power and the normally open output provides a discrete PNP/NPN output. The sensor is an M18 thread barrel sensor of ULTEM™ plastic with an M12 4-pin male micro connector. The enclosure is made of ULTEM with silicone rubber front. Its dimensions are 73.91mm x (length) x 18mm (width) x 18mm x (height). It weighs 0.033kg. The sensor is compliant with CE and UL standards and NEMA 4X (indoor use only) and IP67 rated. It is suitable for packaging, automotive, food and beverage processing applications. This product is certified by CE and UL. The Hyde Park ultrasonic sensors operate in diffuse, reflex and thru beam modes. This range of sensors even includes long distance detection models. Hyde Park ultrasonic sensors perform contactless, reliable, and high performance detection regardless of the target's shape, texture, color, or transparency.
Specifications
Environment
- Product Certifications
- UL
- Resistance To Electromagnetic Fields
- 10 V/m level 3 IEC 61000-4-3
- Relative Humidity
- 100-100 % without condensation
- Vibration Resistance
- +/-1 mm 10-55 Hz)IEC 60068-2-6
- Marking
- CE
- Ip Degree Of Protection
- IP67
Ambient Air Temperature For Operation0-60 °C
Ambient Air Temperature For Storage-40-100 °C
Nema Degree Of ProtectionNEMA 4X indoor use only)
Shock Resistance30 gn in all 3 axes 11 ms IEC 60068-2-27
Resistance To Fast Transients1 kV level 3 IEC 61000-4-4
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Eu Rohs Directive
- Not applicable, out of EU RoHS legal scope
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Reach RegulationReference contains Substances of Very High Concern above the threshold
Complementary
- Repeat Accuracy
- 0.07 %
- Height
- 18 mm
- Maximum Switching Current
- 100 mA reverse polarity protection
- Width
- 18 mm
- [Sn] Nominal Sensing Distance
- 152.4-152.4 mm
- [Sd] Sensing Range
- 25.4-152.4 mm
- Net Weight
- 0.033 kg
- Maximum Differential Travel
- 0.35 mm
Beam Angle7 °
Minimum Size Of Detected Objectcylinder diameter 1.59 mm - up to 63.5 mm sensing distance
Transmission Frequency500 kHz
Depth18 mm
Blind Zone19-19 mm
Length73.91 mm
Current Consumption60 mA
Specifications
- Iso Thread
- M18 x 1
- Series Name
- Superprox 600
- Discrete Output Function
- 1 NO
- Range Of Product
- Hyde Park
- Product Specific Application
- discrete proximity
- Electrical Connection
- male connector M12 4 pins
- Enclosure Material
- ULTEM
- Material
- plastic
- [Us] Rated Supply Voltage
- 12...24 V DC overload and short-circuit protection
Type Of Sensing Windowfixed
Discrete Output TypePNP/NPN
Type Of Output Signaldiscrete
Supply Voltage Limits10-28 V DC
Sensor Typeultrasonic sensor
Sensor Designcylindrical M18
Front Materialsilicone rubber
Device Short NameSM650
Wiring Technique4-wire
