Description

A high performance, 240 x 180 thermal imaging camera. Includes wireless and LaserSharp™ auto focus making it ideal for maintenance professionals.

LaserSharp® Auto Focus - get consistently in-focus images. Every. Single. Time. Utilizing precision laser technology, focus on your target with pinpoint accuracy and get the correct image and temperature measurements you need. Troubleshooting has never been easier.
Fluke Connect™ App – See It. Save It. Share It. All the facts, right in the field
See the crucial details needed to help clearly identify potential problems with precisely blended visual and infrared images – only with IR Fusion® technology with AutoBlend™ mode
Faster communication with wireless image transfer directly to PC, Apple® iPhone® or iPad®
One-handed, easy-to-use interface
Ruggedized Touchscreen Display (Capacitive) 8.9 cm (3.5 in) diagonal landscape color VGA (640 x 480) LCD with backlight for quick menu navigation
Capture additional digital images to show location or additional site details with IR-PhotoNotes™ Annotation System
Voice recording and annotation gets additional details saved with the image file
Optional interchangeable lenses for greater flexibility in additional applications
Rechargeable, field replaceable smart batteries with five-segment LED display to show charge levels
5 MP industrial-performance digital camera for high definition image quality
Included SmartView® and SmartView Mobile App Analysis and Reporting Software

Temperature measurement range	-20 °C to +650 °C (-4 °F to+1202 °F)
Minimum focus distance	15 cm (approx. 6 in)
Wireless connectivity	Fluke Connect™ app compatible. Wireless connectivity to PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi to LAN1
Display	Touchscreen capacitive 3.5 inch diagonal landscape color VGA (640 x 480) LCD with backlight
IFOV (spatial resolution)	1.75 mRad
Thermal sensitivity (NETD)	≤ 0.05 °C at 30 °C target temp (50 mK)
Optional lenses	Telephoto lens, wide angle lens
Detector resolution	240x180 (43,200 pixels)

Frame rate	60 Hz or 9 Hz versions
Design	Rugged, ergonomic design for one-handed use
IR-Fusion® technology	IR-Fusion® AutoBlend™ mode and Picture-in-Picture
Built-in digital camera (visible light)	5 megapixel industrial performance
Focus system	LaserSharp® Auto Focus for consistently in-focus images, manual focus
Field of view	24 °H x 17 °V
Laser distance meter	Yes

IR-PhotoNotes™	Yes
Streaming video (remote display)	Via USB or WiFi hot spot to PC or via HDMI to HDMI compatible screen
Auto capture (temperature and interval)	Yes
Extensive memory options	Removable micro SD memory card, on-board flash memory, save-to-USB capability, direct download via USB-to-PC connection

Video recording	Standard and radiometric
SmartView® software	SmartView® software, Fluke Connect™1, and SmartView® Mobile App—full analysis and reporting software
Voice annotation	60 seconds maximum recording time per image; reviewable playback on camera
File formats image	Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2) No analysis software required for non-radiometric (.bmp, .jpg and .avi) files

AC battery charging system	Two-bay battery charger or in imager charging. Optional 12 V automotive charging adapter

Batteries (field-replaceable, rechargeable)	Two lithium ion smart battery packs with five-segment LED display to show charge level

On-screen transmission correction	Yes
On-screen emissivity correction	Yes (both value and table)

Accuracy	± 2 °C or 2 % (at 25 °C nominal, whichever is greater)
On-screen reflected background temperature compensation	Yes

Weight (battery included)	1.04 Kg (2.3 lb)
Warranty	Two-years (standard), extended warranties are available
Drop	Engineered to withstand 2 meter (6.5 feet) drop with standard lens
Color palettes	8 standard and 8 Ultra Contrast™: Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
Spot temp	Hot and cold spot markers

Center box	Expandable-contractible measurement box with MIN-MAX-AVG temp
Size (H x W x L)	27.7 cm x 12.2 cm x 16.7 cm (10.9 in x 4.8 in x 6.5 in)
Color alarms (temperature alarms)	High-temperature, low-temperature, and isotherm
Enclosure rating	IP54 (protected against dust, limited ingress; protection against water spray from all directions)
User-definable spot markers	3 user definable spot markers on camera and in SmartView® software
