Schneider Electric GB2CD10 TeSys GB2 Circuit Breaker 1P+N 5A 2kA at 240V DIN Rail Mounted

MPN: GB2CD10
PPN: SCH-GB2CD10
UNSPSC: 39121633

$77.34

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys GB circuit breaker, 2 poles (1P+N), 5A/250V IEC/277V UL, for the protection of industrial equipment control circuits. It provides thermal magnetic protection with a magnetic tripping level at 66A (13 In) and breaking capacity Icu 2kA@240V. It can also be used for protection of DC loads up to 5A/48V DC-13 with a breaking capacity Icu 1.5kA@24V. Compact device (30mm wide), mounting on 35mm DIN-rail, control by toggle lever (start-stop guaranteed for 8000 cycles). Sold in lots of 3 units. Multi standards certified (IEC, UL, CSA).

Features

Provides thermal-magnetic protection with a magnetic tripping level
Network type can be AC & DC
Devices can be mounted on all types of 35mm symmetric rails and Telequick mounting plates
Circuit breakers are Tamper proof
Easy to maintain

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	France
Depth	67 mm

Weight	63 g

Complementary Attributes

Ue Rated Operational Voltage	250 V AC 50/60 Hz IEC 60947-2, 277 V AC 60 Hz CSA C22.2 No 235, 277 V AC 60 Hz UL 107748 V DC
Rated Current	5 A
Uimp Rated Impulse Withstand Voltage	4 kV IEC 60947-2

Line Rated Current	5 A
Ics Rated Service Short Circuit Breaking Capacity	75 % 230/240 V AC 50/60 Hz IEC 60947-2

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Mechanical Robustness	shocks 22 Gn for 20 ms IEC 60068-2-27, vibrations 5 Gn, 5...110 Hz IEC 60068-2-6
Mounting Support	rail, plate, rail
Connections Terminals	connector 2 0.75-2.5 mm²flexible with cable endconnector 1 0.75-6 mm²solid without cable end, connector 2 0.75-4 mm²solid without cable endconnector 1 0.75-4 mm²flexible with cable end
Carbon Footprint Of The Distribution Phase A4	0, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase A5	0 kg CO2 eq., 0.004250779378920532
Carbon Footprint Of The Use Phase B2 B3 B4 B6	2 kg CO2 eq., 2.363720566749677
Local Publishable Date	2026-06-27
Device Type	LV equipment - Low voltage circuit breaker
Traceability	No
Average Life Duration	15 year(s)
Weee Scope	In
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	2
Function Option Id	STANDARD
Product Kit Identifier	N
Control Type	toggle
Device Short Name	GB2
Energy Efficiency Optimized	False
Magnetic Tripping Current	66-66 A
Mounting Mode	by clips
Network Type	AC/DC
Power Dissipation Per Pole	2 W
Product Name	TeSys GB2
Protective Treatment	TC
Range	TeSys
Software Version	v6.2.4
Tightening Torque	1.2 N.m connector
Trip Unit Technology	thermal-magnetic
R Magnetic Tripping Current	66-66 A
Database Version	2024-01
Height Nominal	74 mm
Nbr. Of Units In Pkg.	1
Halogen Free Status	Halogen free plastic parts product
Functional Unit Description	Protect the installation against overloads and short circuits and protect people and premises at risk of fire or explosion against insulation defects in a circuit with rated voltage 250V (Ue), rated current 2A (In), with 1P+N poles, a rated breaking capacity 15kA (Icn), and, in the Industrial application areas, while protecting them against the penetration of solid objects and liquids (IP20) in accordance with the standard IEC 62262, according to the appropriate use scenario, and during the reference service life of the product of 20 years.
Functional Unit Unit	unit
Energy Consumption On Product Lifetime In Kwh	26.28

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market Segmentation	Commercial, Industrial
Mounting Position	horizontal, vertical
Utilisation Category	category A IEC 60947-2DC-12 IEC 60947-5-1, DC-13 IEC 60947-5-1
Certificate Agency	UL, CSA
Carbon Footprint Of The End Of Life Phase C1 To C4	0.15772915525205403, 0.2 kg CO2 eq.
Carbon Footprint Of The Manufacturing Phase A1 To A3	0.4 kg CO2 eq., 0.4138347258683495
Local Data Status	Publishable
Return Indicator	N
Serviceability	No
Field Service Division	PPIBS
Weee Applicability	Finished product
Weee Product Category	5
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	2023
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	2
Function Option	Standard
Compatibility Code	GB2
Device Application	control
Electrical Durability	8000 cycles
Fire Resistance	960 °C IEC 60695-2-1
Mechanical Durability	8000 cycles
Network Frequency	50/60 Hz IEC 60947-2
Number Of Poles	1P + N
Product Availability	Non-Stock - Not normally stocked in distribution facility
Product Or Component Type	circuit breaker
Quantity Per Set	set of 6
Returnability	No
Sustainable Packaging	Yes
Total Lifecycle Carbon Footprint	3 kg CO2 eq.
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Rated Current 1	5 A
Data Source	extrapolated product
Width Nominal	15 mm
Customs Code	8536200020
Warranty In Months	18
Functional Unit Quantity	1
Reference Lifetime In Y	20
Recyclability Potential In %	36

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Take Back	No
Halogene Performance	Halogen free plastic parts product
Toxic Heavy Metal Free	Yes
Carbon Footprint	2.9395352272490007
Ambient Air Temperature For Operation	-20-60 °C-20-60 °C
Eu Rohs Directive	Compliant
Ip Degree Of Protection	IP20 IEC 60529
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP2306023EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent external review

Ambient Air Temperature For Storage	-40-80 °C, -40-80 °C
Reach Free Shvc	Yes
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
9 Mm Pitches	2
Environmental Disclosure	ENVPEP2306023EN
Halogen Content Performance	Halogen free plastic parts product
Operating Altitude	9842.52 ft (3000 m)
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2025-04-01
Psr Version	PSR-0005-ed3-2023 06 06
