Square D B11.5 Thermal Unit, Type S, Melting Alloy, Class 20, 20 Inch Length
- MPN: B11.5
- UPC: 785901587484
- PPN: SCH-B11.5
CAD
$49.86
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Linergy NEMA sectional terminal blocks are for terminating wire and are designed to NEMA standards. This Square D terminal block mounting track is designed specifically for 9080G terminal blocks. The track is pre-punched with oblong slots to make mounting the track to the panel easier. This terminal block track is 20 inches long. This track is made of galvanized steel.
Features
- Engineered as a precision-calibrated heating element, this Square D by Schneider Electric B Series thermal unit constantly monitors the current traveling to your motor windings. In the event of a sustained overload or a locked-rotor condition, the excess current generates proportional thermal energy within the element to safely trip the starter, cutting off power before catastrophic winding insulation breakdown or permanent motor damage can occur.
- Utilizing a dependable, high-accuracy melting alloy sensing method, this thermal unit features a durable one-piece construction with a factory-sealed solder reservoir and an internal mechanical ratchet wheel. When current spikes past safe limits, the internal alloy melts at a precise thermal threshold, instantly releasing the ratchet mechanism to open the control circuit contacts a physics-based approach that completely eliminates the calibration drift common in standard bimetallic alternatives.
