Bussmann S506-315-R Time-Delay Fuse 315A 250V 0.787 Inch x 0.197 Inch Glass Tube

MPN: S506-315-R
UPC: 051712650236
PPN: BUS-S506-315-R

Spec sheet

Compare

Loading compare button...

In Stock

Company Stock:

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$4.13/ EA

Qty:

Loading add to cart quantity...

Description

Time-Delay Fuse 315A 250V 0.787 Inch x 0.197 Inch Glass Tube

Specifications

Type: Small dimension, European (IEC)

Amperage Rating: 315A

Interrupt Rating: 35A at 250 Vac

Packaging Type: Standard

Material: Glass tube, nickel-plated brass endcaps

Connection: Ferrule end X ferrule end

Length: .787 IN

Weight: .005 LB

ApplicationElectronic circuits

Voltage Rating250 Vac or less, 32 Vdc (self certified)

Fuse IndicatorNon Indicating

Voltage DropMaximum: 68.5 mV

Frequency Rating50 Hz

Height.787 IN

Width.197 IN
