Blackburn ABP 6350 C Aluminum Overhead Transformer Eyebolt Connector 6-13/16 Inch, 5/8 x 4 Stud, 6 Conductors
- MPN: ABP 6350 C
- UPC: 783786686469
- PPN: T-B-ABP 6350 C
CAD
$156.47
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Aluminum Overhead Transformer Eyebolt Multi-Tap Set Screw Connectors, length 6-13/16 inch, stud size 5/8 X 4, cable range 6-350, outlets 6, with Oxide Inhibitor
Documentation & Downloads
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 39121409 Wire connectors
- Brand Name
- Blackburn
- Special Features
- Made from high-strength Aluminum Alloy to maintain constant bolting pressure on conductors. Screws designed for optimum electrical connection and maximum conductor-contact pressure. Dual-rated for use with Aluminum and Copper conductors.
- Standard
- Meets or exceedds ANSI C119.4 specifications.
- Connection
- Mechanical/Screw
- Number Of Conductors
- 6
- Finish
- Bare
- Insulation
- None
- Environmental Conditions
- All Seasons / Conditions
IGCC4543 Wire connectors
TypeAluminum Overhead Transformer Eyebolt Multi-Tap Set-Screw Connector
ApplicationDesigned with factory-mounted 90 Degree angle copper studs for installation in pole-type transformers with secondary eyebolt connections.
Size6-13/16 inch
Wire Size6-350
MaterialAluminum
Voltage RatingNone Since Uninsulated
Temperature Ratingup to 90 Degrees C.
Packaging
- Outer Quantity
- 25
- Weight Uom
- 1.07 lbs. Each
Outer Dimensions (inches)1x1x1
