Telemecanique Sensors XXSIDPC04Q Ultrasonic proximity sensor XXSID, cylindrical, output PNP, 24 V DC, adjustable sensing range
- MPN: XXSIDPC04Q
- PPN: TES-XXSIDPC04Q
CAD
$294.82
/ EA
Available to Order from Manufacturer
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Ultrasonic proximity sensor XXSID, cylindrical, output PNP, 24 V DC, adjustable sensing range
Documentation & Downloads
Specifications
Key Specifications
| Indivisible sale quantity | 1 |
|---|
| Commercial status | Commercialised |
|---|
Complementary
| Voltage drop | 1 V |
|---|
| Delay first up | 20 ms |
|---|
Environment
| IP degree of protection | IP67 conforming to IEC 60529 |
|---|---|
| Standards | IEC 60947-5-2 |
| Vibration resistance | +/-1 mm conforming to IEC 60068-2-6 (f = 10-55 Hz) |
| Marking | CE |
|---|---|
| Product certifications | UL |
| Shock resistance | 30 gn in all 3 axes for 11 ms conforming to IEC 60068-2-27 |
Main
| Range of product | Telemecanique Ultrasonic sensors XX |
|---|---|
| Series name | General purpose |
| Sensor design | Cylindrical M12 |
| Material | Plastic |
| Rated supply voltage (Us) | 12...24 V DC with reverse polarity protection |
| Sensor type | Ultrasonic sensor |
|---|---|
| Sensor name | XXS |
| Detection system | Diffuse |
| Type of output signal | Discrete |
