Schneider Electric SQR226U1WHWM Dimmer, X Series, rocker, 600W, single pole, 3 way, WiFi , Matter, white
- MPN: SQR226U1WHWM
- PPN: SCH-SQR226U1WHWM
- UNSPSC: 39122206
CAD
$53.34
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
These WiFi enabled Square D dimmers provide energy monitoring, with Wi-Fi connectivity, to bring intelligent IoT connectivity to your home. It retains the classic functionality of a traditional light switch while featuring a modern aesthetic and app-based control to adjust the dimming levels remotely. The device is Matter Compliant and supports seamless communication among IoT devices across platforms, regardless of manufacturers. With the Schneider Home app, you can commission and control X Series Wi-Fi devices from anywhere without a hub. Schneider Home mobile app supports integration with popular voice assistants like Amazon's Alexa and Google Assistant for more comprehensive automation. Ideal for hub-free new construction and remodeling projects. Allows you to understand when and where you use electricity through the built-in energy monitoring features. Complete the look with one of the Square D X Series cover plates (not included) that easily snaps into place for a modern, flush-facing finish to your walls. Enjoy a consistent look across your room or home with the full line of Square D X Series switches, dimmers, sensors, and receptacles. It is part of the Schneider Home integrated energy management system, which provides monitoring control and automation of your home's energy systems to save money, reduce carbon impact and enjoy energy resiliency.
Features
- Effortlessly adjust lighting with wireless dimming
- Supports seamless communication among IoT devices
- Control and monitor your energy consumption all from the Schneider Home app
- For incandescent and halogen bulbs up to 600W and LED bulbs up to 150W
- Integratable with Alexa/Google/Apple
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | China |
|---|---|
| Weight | 176.05 g |
| Actuator | rocker |
|---|---|
| Depth | 47 mm |
Communications & Management Attributes
| Communication Network Type | Wi-Fi, Wi-Fi (2.4-2.4 GHz), 10 mW at < 50 m, matter compliance |
|---|
Complementary Attributes
| Ie Rated Operational Current Ac | 15 A |
|---|
| Ue Rated Operational Voltage | 120 V |
|---|
Important Information Attributes
| Persona Type Ids | EUA, LC, SC |
|---|---|
| Carbon Footprint Of The Distribution Phase A4 | 0.05070853102285775, 0.1 kg CO2 eq. |
| Carbon Footprint Of The Installation Phase A5 | 0.11175451975882157, 0.1 kg CO2 eq. |
| Carbon Footprint Of The Use Phase B2 B3 B4 B6 | 22 kg CO2 eq., 22.413 |
| Local Publishable Date | 2026-08-19 |
| Use Carbon Footprint | 22.413 |
| Weee Scope | In |
| Scope Perimeter | Outside of Europe |
| End Of Life Doc Ref | ENVEOLI2011020EN |
| Reach Full Compliance Status Id | CONTAINS_SVHC |
| Rohs Eur In Scope | Yes |
| Rohs Eur Conformity Date | 2532 |
| China Rohs In Scope | No |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 1 |
| Function Option | Standard |
| Market Segmentation | Residential |
| Actuator | rocker |
| Device Application | control |
| Load Type | halogen 0...600 W |
| Material | plastic: strap |
| Mounting Mode | by screws |
| Number Of Gangs | 1 gang |
| Number Of Ways | 3 |
| Product Or Component Type | connected dimmer |
| Range | Square D X Series |
| Software Version | v5.9.4 |
| Sustainable Packaging | No |
| Total Lifecycle Carbon Footprint | 31 kg CO2 eq. |
| Main Color Tint | white |
| Database Version | 2022-01 |
| Height Nominal | 104 mm |
| Certificate Agency | cULus |
| Customs Code | 8537109170 |
| Functional Unit Description | The product can be used for single pole or 3-Way with Rocker Switch, the LED light can be adjusted manually and the switch can be controlled remotely. Air-Gap Switch feature meets UL requirement and disconnect power from load locally, refer to standard 802.11 b/g/n. Its functional units meet the following technical indicators:& 10- Voltage: 120VAC, 60HZ& 10- Dimmable LED: 1.25A (150W) |
| Functional Unit Unit | unit |
| Recyclability Potential In % | 32 |
| Persona Type Names | Consumer, Contractor, Electrician |
|---|---|
| Carbon Footprint Of The End Of Life Phase C1 To C4 | 0.2 kg CO2 eq., 0.17434890457364768 |
| Carbon Footprint Of The Manufacturing Phase A1 To A3 | 9 kg CO2 eq., 8.596438198595859 |
| Local Data Status | Publishable |
| Return Indicator | Y |
| Weee Applicability | Finished product |
| Weee Product Category | 5 |
| Eoli Availability Display | Yes |
| Reach Full Compliance Status | Reference contains Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Reference contains Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| China Rohs Label | 1 |
| Without Single Use Plastic | No |
| Tier Id | 1 |
| Function Option Id | STANDARD |
| Market Segmentation Id | RESIDENTIAL |
| Product Kit Identifier | N |
| Aesthetic Name | X Series |
| Energy Efficiency Optimized | False |
| Market Segment | residential |
| Mobile App Name | Schneider Home |
| Network Type | AC |
| Number Of Poles | 1 |
| Product Availability | Stock - Normally stocked in distribution facility |
| Quantity Per Set | 1 piece |
| Returnability | Yes |
| Surface Finish | Matte |
| Targeted Channel | retail |
| Color Tint | white |
| Connections Terminals | phase and neutral 4 screw terminal copper |
| Data Source | extrapolated product |
| Width Nominal | 51 mm |
| Nbr. Of Units In Pkg. | 1 |
| Warranty In Months | 18 |
| Functional Unit Quantity | 1 |
| Reference Lifetime In Y | 10 |
Environment Attributes Main
| China Rohs Regulation | Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope) |
|---|---|
| Take Back | No |
| Recycled Metal Content At Cr Level | 0 % |
| Mercury Free | Yes |
| Circularity Profile | ENVEOLI2011020EN |
| Eu Rohs Directive | Compliant |
| Packaging Without Single Use Plastic | No |
| Pep Code | ENVPEP2011020_V2 |
| Pcr Version | PEP-PCR-ed4-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
| Reach Regulation | Free of Substances of Very High Concern above the threshold, Reference contains Substances of Very High Concern above the threshold |
|---|---|
| Reach Free Shvc | Yes |
| Toxic Heavy Metal Free | Yes |
| Carbon Footprint | 31.34625015395119 |
| Environmental Disclosure | ENVPEP2011020_V2 |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Free Of Svhc | Yes |
| Pep Verification Date | 2026-05-26 |
| Psr Version | PSR-0005-ed2-2016 03 29 |
General Attributes
| Product Or Component Type | connected dimmer |
|---|
ETIM
| ETIM 8 | EC000025 |
|---|---|
| ETIM 10 | EC000025 |
| ETIM 9 | EC000025 |
|---|
Overview Attributes
| Device Presentation | mechanism with fixing frame |
|---|
