3M QI-5/16-220 Cold Shrink Quick Insulator, 1 kV, For 1-2/0 AWG Conductors, 0.20-0.65 in O.D., 10/case
- MPN: QI-5/16-220
- UPC: 051128577509
- PPN: MMM-QI-5/16-220
CAD
$106.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Cold Shrink Quick Insulator, 1 kV, For 1-2/0 AWG Conductors, 0.20-0.65 in O.D., 10/case
Specifications
Key Specifications
| 3M ID | 80611443500 |
|---|---|
| Cable End Recovered | 1 Inch |
| Case Quantity | 10 |
| Conductor Legs Expanded | 1 Inch |
| Conductor Material | Aluminum, Copper |
| Connector Included | No |
| Elongation | 750 % |
| Indoor/Outdoor | Both |
| Insulation O.D. Range (Metric) | 5.1-16.5 mm |
| Maximum Connector Length | 2.75 in |
| Number of Outlets | 4 |
| Product Type | Splice |
| RoHS EU Comments | RoHS 2011/65/EU compliant without exemption |
| Splice Type | Cold Shrink |
| Voltage | 1 kV |
| Cable End Expanded | 2.35 Inch |
|---|---|
| Cable Type | Power Cable |
| Color | Black |
| Conductor Legs Recovered | 0.35 Inch |
| Conductor Sizes | 1 AWG, 1/0 AWG, 2 AWG, 2/0 AWG, 4 AWG, 6 AWG, 8 AWG |
| Dielectric Strength (V/mil) | 365 V/mil |
| Flame Retardant | Yes |
| Insulation O.D. Range | 0.20-0.65 in |
| Material | Semi-Rigid, Flame Retardant Polyolefin |
| Maximum Connector Length (metric) | 69.9 mm |
| Outlet Style | 4-Way |
| RoHS 2011/65/EU Compliant | Yes |
| Shielding Type | Non-shielded |
| Trademark | 3M |
